The Optimization of Wire Bonding Parameters and Quality Prediction Model Based on Neural Network

Abstract:

In this article, the parameters affecting the quality of wire bonding are analyzed by orthogonal testing with the methods of variance analysis and F tests. By analyzing the results, parameters that have a major impact on the quality of wire bonding are optimized. Because the relationship is complicated and non-linear between the impacting parameters and bonding quality, this article introduces a neural network algorithm of BPNN to build a model describing it. The structural parameters of the neural network are identified and a quality prediction model of wire bonding is established in this article. The model is validated, the results show that this proposed model has higher precision and it can accurately reflect the trends of the bonding quality indicators.

• Periodical: Advanced Materials Research (Volumes 542-543)
• Pages: 976-980
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.542-543.976
• Online since: June 2012
• Authors: Xiao Dan Guan, Gang Chen, Wan Lei Liang
• Keywords: Neural Network (NN), Orthogonal Testing, Quality Prediction, Wire Bonding

References

[1] Catching up to Flip Chip Technology, Connections Magazine, 2001, Vol.1.

[2] Hu S J, Lim G E E.Study of temperature parameter on the thermosonic gold wire bonding of high-speed CMO S.IEEE Trans on Components, Hybrids, and Manufacturing, 1991.

DOI: 10.1109/33.105145

[3] HeJ, zhuP.Parameter sensitivity analysis for thermo sonic bonding process by finite element method.2007 8th International Conference on Electronics Packaging Technology, 2007.

DOI: 10.1109/icept.2007.4441509

[4] Sheaffer M L L.How to optimize and control the wire bonding process. Solid State Technology, 1991.

[5] Ding Y, Kim J K T P.NIrtmerical analysis of ultrasonic wire bonding: Effects of bonding parameters on contact pressure and frictional energy. Mechanics of Materials, 2006.

DOI: 10.1016/j.mechmat.2005.05.007

[6] HanL, gaoRZ, zhongJ, etAl.Wire bonding dynamics monitoring by wavelet analysis. Sensors and Actuators A. Sensors and Actuators A, 2007.

[7] LoYL, tsaoCC.Integrated Taguchi Method and Neural Network Analysis of Physical Profiling in the Wire bonding Process. IEEE Transactions on Components and Packaging Technologies, 2002.

[8] Hagan M T, Demuth H B, Beale M H. Neural network design. Boston: PWS Publishing, 1996.

[9] Chen J L, Lin Y C. A new approach in free air ball formation process parameters analysis. IEEE Transactions on Electronics Packaging Manufacturing, 2000.

DOI: 10.1109/6104.846934

[10] SuCT, chiangTL.Optimal design for a ball grid array wire bonding process using a neuro-genetic approach.IEEE Transactions on Electronics Packaging manufacturing, 2005.

DOI: 10.1109/tepm.2002.1000478
