Thermal Analysis of an Anodic Oxide Coating Diesel Engine Piston Using 3-D Finite Element Method

Abstract:

According to the phenomenon that the piston’s reliability and durability have been significantly weakened due to its high temperature, hard anodizing is used to hinder the heat transfer from the combustion gas to the metal base of the piston. Thermal analyses are performed on pistons with different thicknesses of anodic oxide coatings. The effects of coatings on the thermal behaviors of the pistons are investigated. The numerical results are compared with each other. It has been shown that the maximum surface temperature of the coated pistons with anodic oxide coating which has low thermal conductivity are significantly improved. Also, considering the hard anodizing process, the 100 ~ 150μm thickness of the anodic oxide coating would meet the requirements of the piston’s reliability.

You might also be interested in these eBooks

Material and Manufacturing Technology III

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 548)

Pages:

450-455

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.548.450

Citation:

Cite this paper

Online since:

July 2012

Authors:

Yu Wei Liu, Wei Zheng Zhang, Yuan Fu Cao

Keywords:

Aluminum Alloy Piston, Anodic Oxide Coating, Finite Element Method (FEM)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] LIU Chang, Research on fatigue life prediction and enhanced design technology of Aluminum alloy piston[D]. June 2011, Beijing Institute of Technology.

Google Scholar

[2] WANG Zhongyu. A Study on the Heat Transfer and the Thermal Intensity of Piston[D]. June 2005, Chongqing University.

Google Scholar

[3] Wirnick S, Pinner R. The surface treatment and finishing of aluminum and its alloys: Vol 2. 4th ed. Teddington: Robert Draper LTD, 1972. 563.

Google Scholar

[4] TIAN Yong-xiang, ZHANG Xi-chao. Three-dimensional FEA for the Thermal Film of Pistons [J]. Chinese Internal Combustion Engine Engineering. 2004, (25): 62-64.

Google Scholar

[5] Annand W.J.D. Heat transfer in the cylinders of reciprocating internal combustion engines [ J ]. Proc. Inst. Mech. Engrs. 1963, (177): 973-990.

Google Scholar

[6] Seale, W. J. Taylor, D.H.C. Spatial variation of heat transfer to pistons and liners of some medium speed diesel engines. Proc. Inst. Mech. Engrs. 1970, (185): 203-218.

DOI: 10.1243/pime_proc_1970_185_030_02

Google Scholar
