Modeling and Simulation of Disc Brake Resistance Load in Low Speed Condition

Abstract:

In this paper, the load simulation of tracked vehicle disc brake in low speed is discussed. The simulation of the resistance load and the control of the disc brake is researched when the resistance load loading on the test bench The simulation results show that, by controlling the input voltage of the disc brake electrohydraulic control portion, the disc brake braking torque can be controlled, the driving resistance simulation of crawler vehicle is realized. At the same time, the simulation has high accuracy, fast response speed, and has better dynamic characteristic. When the tracked vehicle is at the process of start, acceleration, deceleration, braking, steering , the engine and the transmission system mainly are in an unstable vehicle system dynamic, the load is dynamic load must be given. In order to investigate the performance of tracked vehicle HMCVT, a dynamic load [1] in the test system to simulate the loading process of tracked vehicle. Eddy current dynamometer can simulate the load [2,3] during a vehicle running a higher speed , the driving load in low speed ( including zero speed ) is simulated by disc brakes .

• Periodical: Advanced Materials Research (Volume 548)
• Pages: 691-695
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.548.691
• Online since: July 2012
• Authors: Yi He, Shao Jie Du, Guang Wei Cheng
• Keywords: Disc Brake, Resistance Load, Simulation, Tracked Vehicle

References

[1] Cheng Guangwei, Zhou Zhili Load Research of the HMT Dynamic Characteristics[J ]. Journal of Huazhong Agricultural University, 2005, S1: 76-78.

[2] Matthew S C, Gary S, Robert S. Development of transmission hardware-in-the-loop test system[C]. SAE paper 2003-01-1027, (2003).

[3] Lu series. Automobile automatic transmission system test technology research [D]. Jilin: Jilin University, (2001).

[4] Cheng Guangwei, Zhou Zhili, Xu Liyou and so on. Tracked vehicle load in the power train test bench simulation [J ]. Tractor and agricultural carriage car, 2006, (4): Vol. 33 12-14.
