Heat Energy Storage Characteristics of a New Type of PCM Heat Exchange Tube

Abstract:

Heat energy storage characteristics of a new type of PCM heat exchange tube was researched, in which it took the traditional double-tube exchanger as the total construction foundation and phase change material(CaCl2•6H2O) was filled in the annular area between the inner tube and the outer tube. As air with different temperatures flowed through the PCM heat exchange tube, temperature measurements were carried out at the inlet and the outlet by the experimental system. The experimental results showed that, a new type of PCM heat exchange tube could store heat energy from the hot air by the phase change material in the annular area, and discharge the stored heat energy into the required fluid if necessary. Thus it has two functions of heat exchange and heat energy storage, and is mainly suitable for recovery and utilizations of heat energy in greenhouses, buildings, air conditioning and manifold industrial afterheat or waste heat.

• Periodical: Advanced Materials Research (Volumes 550-553)
• Pages: 3131-3134
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.550-553.3131
• Online since: July 2012
• Authors: Xiao Qin Zhu, Zhao Sheng Cao, Zi Yue Zhu, Jing Hua Chang, Hai Ming Gu, Hai Bin Yang
• Keywords: CaCl₂·6H₂O, Heat Energy Storage, Heat Exchange Tube, Phase Change Materials (PCM)

References

[1] X.Q. Zhu, Y.F. Yang, S.L.Li, et al: Chemical Engineering (in Chinese). Vol. 36(2008), p.23

[2] X.Q. Zhu, J.Hu, Y.F. Yang, et al: Advanced Materials Research. Vols. 79-82(2009), p.1815

[3] A.Hasan, S.J.McCormack, M.J. Huang, et al: Solar Energy. Vol. 84(2010), p.1601

[4] X.Q. Zhu, J.M. Liu: Process equipment fundamentals (Chemical Industry Press, China, 2011)

[5] F.P. Incropera and D.P. Dewitt: Fundamentals of Heat and mass transfer (Wiley Publishing Company, U.S.A, 2001)
