The Hot-Plugging Clamp Design of the Petrochemical Equipment Pipeline

Abstract:

Liquid leaking accidents of petrochemical equipment were always happened in weld joint of the pipeline. In order to deal with the accidents, the hot-plugging technique was adopted. And the clamp design which was the difficult point of this technology must be valued. In this paper, the hot-plugging technique and the structure of the clamp were introduced. And the calculation formula of the clamp thickness was deduced based on the influence of the injecting hole on the clamp and GB150-98. And the results would be the fundament of further study of the hot-plugging clamp design

• Periodical: Advanced Materials Research (Volumes 550-553)
• Pages: 3206-3209
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.550-553.3206
• Online since: July 2012
• Authors: Jin Gang Wang, Fu Jing Fan
• Keywords: Clamp, Hot-Plugging Technique, Petrochemical Equipment

References

[1] Yiwei Hu "Dynamic Sealing Technology: Leaking and Plugging" National Defense Industry Press.(1998),pp.110-117

[2] Jinrong Wang. " Pressure Vessel and Pressure Equipment Pressure Seal Technology" Tianjin University Press.(2007).03,pp.28-32

[3] National Pressure Vessel Committee for Standardization.GB150-1998 Steel Pressure Vessel. Beijing: Standards Press of China,(1998),pp.22-30
