A Method of Robust Control for Nonlinear Inverted Pendulum System

Abstract:

In this paper, the controller of inverted pendulum with parametric uncertainty and nonlinearity was proposed. The controller was composed of two terms. Control law of linear part of the system was obtained by Coordinate Transfer and Backstepping algorithm. To the nonlinear part and uncertainty of the system which are usually not accords with the form of Backstepping algorithm, a BP neural network was applied to the design of the controller. Method submitted in this paper was less restrictive to the form of the nonlinear system, and has a wider universality. At the end of the paper, simulations proved the effectiveness of the proposed method.

• Periodical: Advanced Materials Research (Volumes 562-564)
• Pages: 1650-1654
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.562-564.1650
• Online since: August 2012
• Authors: Ke Yong Shao, Miao Miao Tian, Qing Yu Wu
• Keywords: Backstepping, Inverted Pendulum, Neural Network (NN), Nonlinear System

References

[1] Chen Daizhan, Hong Yiguang and Qin Huashu: Backstepping Forms of Multi-input Nonlinear Systems. Control Theory and Applications, Vol. 15, No. 6 (1998), pp.824-829.

[2] Yang Junhua, Wu Jie and Hu Yueming: Principle of Backstepping and Its Applications in Nonlinear Robust Control. Control and Decision(December 2002), pp.641-647.

[3] Jia Qingzhong, Liu Yongshan and Liu Zaozhen: Backstepping Design for Uncertain Nonlinear Systems. Journal of System Simulating, Vol. 19, No. 21(2007), pp.5002-5007.

[4] He Naibao, Jiang Changsheng and Gao Qiang: Adaptive Tracking Control Based on Backstepping for a Class of Uncertain Nonlinear Systems. Journal of Harbin Institute of Technology, Vol. 41, No. 5(2009), pp.169-171.

DOI: 10.1109/ccdc.2008.4597874

[5] Olfati-Saber: Fixed point controllers and stabilization of the cart-pole system and the rotating pendulum. M Proc. of the38th IEEE Conference on Decision and Control, Phoenix(1999), pp.1174-21181.

DOI: 10.1109/cdc.1999.830086

[6] Chen Jie, Li Zhiping and Zhangguozhu: Adaptive Robust Control of Variable Structure Neural Network. Acta Automatica Sinica, Vol. 36, No. 1, pp.174-178.

DOI: 10.3724/sp.j.1004.2010.00174

[7] Chen Mou, Jiang Changsheng and Wu Qingxian: Control for Inverted Pendulum Based on Nonlinear Method. Control Theory and Applications, Vol. 21, No. 5(2004), pp.684-688.

[8] Zeng Deliang, Liu Yuyan, Liu Jizhen, Zhang Lijuan and Quhaiyun: A Method of H∞ Optimum Control for Inverted Pendulum. Control Theory and Applications, Vol. 21, No. 5(2004), pp.717-719.

[9] Biling S A and Tsang K M: Spectral analysis for nonlinear systems. Part: Interpretation of nonlinear frequency response function. Mechanical Systems and Signal Processing, Vol. 3, No. 4(1989), pp.341-359.

DOI: 10.1016/0888-3270(89)90042-3

[10] Gugao Technology (shenzhen) Co. LTD: Experiments of Inverted Pendulum and Automatic Control Theory (2005).
