A Comprehensive Study on Surface Roughness in Machining of AISI D2 Hardened Steel

Abstract:

Hard milling of hardened steel has wide application in mould and die industries. However, milling induced surface finish has received little attention. An experimental investigation is conducted to comprehensively characterize the surface roughness of AISI D2 hardened steel (58-62 HRC) in end milling operation using TiAlN/AlCrN multilayer coated carbide. Surface roughness (Ra) was examined at different cutting speed (v) and radial depth of cut (dr) while the measurement was taken in feed speed, Vf and cutting speed, Vc directions. The experimental results show that the milled surface is anisotropic in nature. Surface roughness values in feed speed direction do not appear to correspond to any definite pattern in relation to cutting speed, while it increases with radial depth-of-cut within the range 0.13-0.24 µm. In cutting speed direction, surface roughness value decreases in the high speed range, while it increases in the high radial depth of cut. Radial depth of cut is the most influencing parameter in surface roughness followed by cutting speed.

• Periodical: Advanced Materials Research (Volume 576)
• Pages: 60-63
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.576.60
• Online since: October 2012
• Authors: N.A.H. Jasni, Mohd Amri Lajis
• Keywords: AISI D2 Hardened Steel, Hard Milling, Surface Roughness (SR), TiAlN/AlCrN Multilayer Coated Carbide

References

[1] P. Koshy, R.C. Dewes, D.K. Aspinwall, High speed end milling of hardened AISI D2 tool steel (~58 HRC), Journal of Material Processing Technology. 127 (2002) 266-273.

DOI: 10.1016/s0924-0136(02)00155-3

[2] W. Grzesik, Advanced Machining Processes of Metallic Materials: Theory, Modelling and Applications. First edition, Oxford, UK: Elsevier (2008).

[3] D.A. Axinte, R.C. Dewes, Surface integrity of hot work steel after high speed milling-experimental data and empirical models, Journal of Materials Processing Technology. 127 (2002) 325-335.

DOI: 10.1016/s0924-0136(02)00282-0

[4] J.P. Davim, Machining: Fundamental and Recent Advances, London: Springer (2008).

[5] E. Aslan, Experimental investigation of cutting tool performance in high speed cutting of hardened X210Cr12 cold work tool steel (62 HRC), Materials & Design 26 (2005) 21-27.

DOI: 10.1016/j.matdes.2004.04.004

[6] Ginting, A., Nouari, M., Surface integrity of dry machined titanium alloys, International Journal of Machine Tools & Manufacture. 49 (2009) 325–332.

DOI: 10.1016/j.ijmachtools.2008.10.011

[7] J. Sun, Y.B. Guo, A comprehensive experimental study on surface integrity by end milling Ti–6Al–4V, Journal of Materials Processing Technology. 209 (2009) 4036–4042.

DOI: 10.1016/j.jmatprotec.2008.09.022

[8] B.M. Gopalsamy, B. Mondal, S. Ghosh, K. Arntz and F. Klocke: submitted to Int J Adv Manuf Technol (2010).

[9] B.M. Gopalsamy, B. Mondal, S. Ghosh, K. Arntz and F. Klocke, Investigations on hard machining of Impax Hi Hard tool steel, Int J Mater Form. 2 (2009) 145-165.

DOI: 10.1007/s12289-009-0400-5

[10] M.M. El-Khabeery, S.M. Saleh, M.R. Ramadan (1991) Some observations of surface integrity of deep drilling holes. Wear, 142: 331–349.

DOI: 10.1016/0043-1648(91)90173-r

[11] J. Vivancos, C.J. Luis, L. Costa, J.A. Ort´ız, Optimal machining parameters selection in high speed milling of hardened steels for injection moulds, Journal of Materials Processing Technology. 155–156 (2004) 1505–1512.

DOI: 10.1016/j.jmatprotec.2004.04.260
