Research on the Auto-Row-Aligning Technology of Root-Tuber Crops Harvesting Machine

Abstract:

Root-tuber crops are buried under the ground, thus, the mechanization harvest should apply digging method. However, the row-aligning angle of the shovel can directly influence the digging effect. Therefore, a set of auto-aligning technological equipments were designed to solve this problem and achieve aligned digging. This paper mainly analyzes the design of above mentioned equipments as below: A right-left angular displacement sensor is added in the front part to achieve auto-induction and signal transformation of the digging angel through comparison of the pressure angle. The adjustment of the control equipment can be achieved by the adjustment of signal when it goes through magnetic exchange valve. And with the help of cross slide way, the digging harvest machine can modulate the shovel timely and efficiently. Experiments demonstrated that such auto-row-aligning equipment can improve the digging effect.

• Periodical: Advanced Materials Research (Volumes 588-589)
• Pages: 1419-1422
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.588-589.1419
• Online since: November 2012
• Authors: Ran Bing Yang, Shu Qi Shang, Xin Cheng Li, Meng Fei Han
• Keywords: Auto-Row-Aligning, Digging Angle, Digging Harvest, Digging Shovel

References

[1] Jiang Xiaojing, Yang Xiaoqiang, Han Jun, et al. Design of Automatic Test System for Engineering Machinery Hydraulic System Based on Modular Instrumentation and Database Measurement Technology [J]: Machine Tool & Hydraulics， Vol. 38(2010)：p.77.

[2] Deng Wenliang, Qiang Baomin. Simulative Research of Synchronization Control of Two Hydraulic Cylinder System Based on Fuzzy-PID: Machine Tool & Hydraulics，Vol. 38(2010)：p.28.

[3] Song Jizhong, in: Technical specifications of quality evaluation for peanut harvesters, edtied by Ministry of agriculture of the people's Republic of China, China, NY (2002), in press.
