Research on Balancing Method for Inertia Force of Slider-Crank Mechanism with Small Linkage Ratio

Abstract:

In view of the difficult balance of inertia force for the slider-crank mechanism, on the basis of analyzing inertia force of the slider-crank mechanism, a new balancing method of inertia force was proposed for the slider-crank mechanism with small linkage ratio, the rotary mass and the moving mass had replaced the mechanism mass, the inertia force of rotary mass was balanced by rotary weight counterbalance, a spring was disposed by slider, it provided variable elastic force and balanced the inertia force of moving mass. Then the balancing method was analyzed deeply and the theoretical derivation was made, the results show that this balancing method would achieved approximately balance for inertia force of the slider-crank mechanism with small linkage ratio.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 2011-2015
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.2011
• Online since: November 2012
• Authors: Rui Yuan, Yu Sun, Wen Hai Fan, Kai Wu, Zheng Jun Chen
• Keywords: Balancing Method, Inertia Force, Linkage Ratio, Slider-Crank Mechanism

References

[1] M R Smith: Mechanisms and Machine Theory (Higher Education Press, china 2001), p.43.

[2] Y Q Yu, Z Li: Dynamics of Modern Machinery (Beijing Polytechnic University Press, China 1998), p.1. (In Chinese).

[3] C L Zhang: Advanced Kinematics Dynamics of Mechanisms (Beijing institute of Technology Press, China 2005), pp.151-155. (In Chinese).

[4] J Huang: Journal of Hubel Polytechnic University, Vol. 17 (2002) No. 2, pp.119-125. (In Chinese).

[5] H W Yue, G Yang and Y C Feng: Mechanical Engineering & Automation, Vol. 127 (2005) No. 6, pp.19-29. (In Chinese).

[6] L Y Liu: Modern Manufacturing Technology and Equipment, Vol. 182(2008) No. 1, pp.6-8. (In Chinese).
