Ladle Transportation Car Frame Finite Element Analysis

Abstract:

Using the mechanical design of the software Solid works to established the 280 t LF the ladle furnace transportation car frame three dimensional model, and by using the finite element analysis of software Cosmos/works to static analysis for the frames, revealing that the frame of structure stress and strain distribution map of the frame, and also reveals that dangerous points and dangerous sections. Using resistance strain gauge to measure 280 t ladle transportation car frame, it is concluded that the frame of stress and strain distributions. Through the electrical measurement test the results were compared with finite element analysis results, further proof that the finite element analysis of the accuracy of the results provides theory basis for the optimization design of the frames.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 841-844
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.841
• Online since: November 2012
• Authors: Ping Tang, Chun Hua Pan
• Keywords: Cosmos/Works, Finite Element Analysis (FEA), Frame

References

[1] G.L. Liu: Solid Works Completely Self-Taught Manual (Science Press, Chinese, 2006)

[2] W.D. Zhang, K.Chen: Mechanical Design and Manufacturing Press, Vol.1001-3997(2005).No.1, P53

[3] H.Zhan, WM Zhao:Mechanical Engineer Press, Vol.1002-2333(2005).No.2,P43

[4] M.Y. Bao, G.J. Cao: Shenyang aviation industry university journal, Vol.1007-1385. (2004).No-P44
