Numerical Simulation on V Shaped Solar Flat-Plate Air Collector

Abstract:

The V-shaped solar flat-plate air collector was design in order to improve the efficiency of solar flat-plate air collector, and the heat transfer model was established on the base of solar collector working principle. Internal temperature distribution of collector and temperature change rule under different sunshine condition is simulated and the relation of collector height, solar radiation intensity and collector efficiency is analyzed. The result showed that internal air temperature of collector increases with collector height increase and gradually achieves a stable value. It will provide a theoretical basis for collector layout of solar house.

• Periodical: Advanced Materials Research (Volumes 594-597)
• Pages: 2175-2178
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.594-597.2175
• Online since: November 2012
• Authors: Ming Dong Chen, Xue Bing Liu
• Keywords: Collector Height, Collector Layout, Heat Transfer Model, Solar House, V-Shaped Solar Flat-Plate Air Collector

References

[1] Hou Hongjuan, Wang Zhifeng, Wang Ruzhu, et a1. Acta Energiae Solaris Sinica, Vol. 25 (2004), pp.310-314. (in chinese)

[2] Muschaweck J, Spirkl W. Solar energy materials and solar cell, Vol. 30 (1993), pp.95-105.

DOI: 10.1016/0927-0248(93)90011-q

[3] KARIM M A, HAWLADER M N. Applied thermal engineering, Vol. 26 (2006), pp.121-130.

[4] Liu Yifu, Huang Kunrong, Wang Yulin. Mechanical research and application, Vol. 1 (2012), pp.65-68. (in chinese)

[5] Zhang Chunjiang, Wang Henglong. Journal of shanghai jiaotong University, Vol. 38 (2004), pp.1655-1659. (in chinese)

[6] Peng Donghua, Chen Zhengqian, Shi Mingheng. Acta Energiae Solaris Sinica, Vol. 30 (2009), pp.911-915. (in chinese)

[7] Chen Ming dong, Shi Yuliang. Transactions of the Chinese Society of Agricultural Engineering, Vol. 27 (2011), pp.232-235(in chinese)

[8] Li Ming,Wang Liuling. Acta Energiae Solaris Sinica, Vol. 29 (2008), pp.272-276(in chinese)

[9] Chen Bin, Liu Lei, Chen Jia, et al. Acta Energiae Solaris Sinica, Vol. 31 (2010), pp.338-344(in chinese) .

[10] Alva S L H, Gonzalez J E, Dukhan N. Journal of solar energy engineering, Vol. 128 (2006), pp.173-177(in chinese).

[11] Ji Jie, Ma Jinwei, Sun Wei, et al. Acta Energiae Solaris Sinica, Vol. 32 (2011), pp.1470-1474 (in chinese) .

[12] Zhao Jun, Ma Yitai, Ma Yuan, et al. Acta Energiae Solaris Sinica,, Vol. 22 (2001), pp.440-442 (in chinese) .

[13] Su Wenjia, Zuo Ran, Zhang Zhiqiang, et al. Acta Energiae Solaris Sinica, Vol. 29 (2008), pp.449-453(in chinese) .
