Parametric Study of Beam to Column Extended Endplate Connection in Fire

Abstract:

In this paper, numerical study results using ABAQUS are presents to demonstrate the failure modes and the behaviour of endplate connection with different parameters at elevated temperature. Numerical models and simulation methodology are first validated by the comparison to experimental data. Then the behaviour of beam and the failure modes endplate connection with different parameters- including beam span, beam load ratio, column cross section, endplate type- are studied. It can be concluded that all these parameters has a effects on the behaviour of the connection, while some parameters has a great influence on the survivability of the joint.

• Periodical: Advanced Materials Research (Volumes 594-597)
• Pages: 779-784
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.594-597.779
• Online since: November 2012
• Authors: Meng Wang*
• Keywords: Bare Steel Frame, Catenary Action, Extended Endplate Connection, Parametric Study

References

[1] NIST. Final report on the collapse of the world trade center towers. USA: National Institute of Standards and Technology; 2005.

[2] Newman GM, Robinson JT, Bailey CG. Fire safety design: A new approach to multi-storey steel-framed buildings. UK: The Steel Construction Institute; 2004.

[3] Ding J, Wang YC. Experimental study of structural fire behavior of steel beam to concrete filled tubular column assemblies with different types of joints. Engineering Structures 2007;29:3485–502.

DOI: 10.1016/j.engstruct.2007.08.018

[4] Yu HX, Burgess IW, Davison JB, Plank RJ. Tying capacity of web cleat connections in fire, Part 1: Test and finite element simulation. Engineering Structures 2009;31:651-663

DOI: 10.1016/j.engstruct.2008.11.005

[5] Yu HX, Burgess IW, Davison JB, Plank RJ. Tying capacity of web cleat connections in fire, Part 2: Development of component-based model. Engineering Structures 2009;31:697-708

DOI: 10.1016/j.engstruct.2008.11.006

[6] Yu HX, Burgess IW, Davison JB, Plank RJ. Experimental investigation of the behaviour of finplate connections in fire. Journal of Constructional Steel Research 2009;65:723–36.

DOI: 10.1016/j.jcsr.2008.02.015

[7] Yu HX, Burgess IW, Davison JB, Plank RJ. Experimental and numerical investigations of the behaviour of flush endplate connections at elevated temperatures. Journal of Structure Engineering 2011;137(1):80–7.

DOI: 10.1061/(asce)st.1943-541x.0000277

[8] Dai XH, Wang YC, Bailey CG. Numerical modelling of structural fire behaviour of restrained steel beam column assemblies using typical joint types. Engineering Structures 2010;32:2337–5

DOI: 10.1016/j.engstruct.2010.04.009

[9] Wang YC, Dai XH, Bailey CG. An experimental study of relative structural fire behaviour and robustness of different types of steel joint in restrained steel frames. Journal of Constructional Steel Research 2011;67:1149–1163

DOI: 10.1016/j.jcsr.2011.02.008

[10] Elsawaf S, Wang YC, Mandal P. Numerical modelling of restrained structural subassemblies of steel beam and CFT columns connected using reverse channels in fire.Engineering Structures 2011;33:1217–31.

DOI: 10.1016/j.engstruct.2010.12.043

[11] Elsawaf S, Wang YC, Methods of improving the survival temperature in Fire of steel beam connected to CFT column using reverse channel connection. Engineering Structures 2012;34:132-146

DOI: 10.1016/j.engstruct.2011.09.004

[12] EN1993-1-2. Eurocode3: Design of steel structures, part1.2: general rules- structural fire design. London: British Standards Institution; 2005.

[13] ABAQUS analysis user's manual version 6.9, ABAQUS Inc.2009.
