Finite Element Analysis on the Steel Transmission Pole

Abstract:

At present, the finite element method is used to calculate the strength and deformation of the steel transmission pole less. Using ANSYS to model steel transmission pole, loading, analysis, the results show that, the traditional method of strength calculation and finite element analysis results are very close, the traditional method of deformation calculation and finite element analysis results has a certain bias. As long as the establishment of three-dimensional model of the steel transmission pole, the applied load and boundary conditions to meet the actual, finite element analysis can provide a more reliable basis for the design and verification of the steel transmission pole.

• Periodical: Advanced Materials Research (Volumes 594-597)
• Pages: 808-811
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.594-597.808
• Online since: November 2012
• Authors: Yan Hai Wang*, Wei Jiang, Hong Wang
• Keywords: ANSYS, Finite Element Method (FEM), Transmission Line Steel, Transmission Pole

References

[1] Zhang Yong,Shi Gang,Liu Zhao. Finite element analysis and design method study for the local buckling of high strength steel equal angles under axial compression[J]. China Civil Engineering Journal, 2011, 44(9):27-34. (In Chinese)

[2] Huang Yu, Deng Hongzhou, Jin Xiaohua. Experimental research and finite element analysis on flexural performance of innovative flange joint used in steel poles [J]. Journal of Building Structures, 2011, 32(10):73-81. (In Chinese)

[3] WANG Cangzhu, YANG Xiaohong, ZHANG Jin. Computer Aided Design of Plug-in Steel Pole of Electricity Transmission Tower [J]. Information On Electric Power, 2002(2): 39- 41. (In Chinese)

[4] ZHANG Diansheng. Power engineering design manual for high voltage transmission line [M].2nd ed. Beijing: China Electric Power Press, 2002: 346-362. (In Chinese)

[5] DL/T5130-2001. Technical regulation for design of steel transmission pole [S]. Beijing: China Electric Power Press, 2002.( In Chinese)
