Numerical Simulation of Heat Flow in a Vehicle Cabin

Abstract:

The heat flow distribution in a simplified 3-D vehicle cabin is predicted when parking in the summer sunshine by using the CFD analysis software. The nature convection and radiation heat transfer from environment to cabin are considered in this simulation. The distribution of transient temperature and velocity at the central and horizontal plane are analyzed respectively. It is shown that the temperature increases by time and there is little temperature difference in the cabin. The highest value is located at the front and both sides cabin after two minutes. The air is essentially stagnant with low velocity and the central compartment has much lower velocity than other regions.

• Periodical: Advanced Materials Research (Volumes 602-604)
• Pages: 1769-1774
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.602-604.1769
• Online since: December 2012
• Authors: Yang Zeng, Masafumi Katsuta
• Keywords: Computational Fluid Dynamics (CFD), Heat Flow, Heat Transfer, Numerical Simulation, Temperature Distribution, Vehicle Cabin

References

[1] Tomohiro Kitagawa, Kiyoshi Kawaguchi, Daisuke Watanabe and Ryota Toyohara: Reducing Temperature in a Parking Automobile under Summer Solar Radiation, 49th Japan Heat Transfer Symposium proceedings (2012).

[2] K. Yamamoto, W.R. Hill, Interior Flow Visualization of a Small Pick-up Truck and A/C Feeling Estimate, SAE International Congress and Exposition, ISSN: 0148-7191, SAE, Detroit, MI, USA (1990).

DOI: 10.4271/900082

[3] Chao-Hsin Lin, A. Lelli Michael, Han Taeyoung, J. Niemiec Robert, C. Hammond Dean, Jr., Experimental and Computational Study of Cooling in a Simplified GM-10 Passenger Compartment, International Congress and Exposition, ISSN: 0148-7191, SAE, Detroit, MI, USA (1991).

DOI: 10.4271/910216

[4] Ambs, R: Improved Passenger Thermal Comfort Prediction in the Preprototype Phase by Transient Interior CFD Analysis Including Mannequins, SAE Paper (2002).

DOI: 10.4271/2002-01-0514

[5] Gokhan Sevilgen, Muhsin Kilic: Transient Numerical Analysis of Airflow and Heat Transfer in a Vehicle Cabin During Heating Period, Int. J. Vehicle Design, Vol. 52, Nos. 1/2/3/4, (2010).

DOI: 10.1504/ijvd.2010.029641

[6] Huajun Zhang, Lan Dai, Guoquan Xu, Yong Li, Wei Chen, WenQuan Tao: Studies of Air-flow and Temperature Fields inside a Passenger Compartment for Improving Thermal Comfort and Saving Energy. Part I: Test/ Numerical Model and Validation, Applied Thermal Engineering 29 (2009).

DOI: 10.1016/j.applthermaleng.2008.10.005

[7] Shinichiro Wakashima: on Developemnt of the Thermal Environment Simulator of an Automobile, 47th Japan Heat Transfer Symposium proceedings (2010).

[8] ANSYS Inc. Fluent Manuals.

[9] Richard C. Farmer, Gary C. Cheng, Yen-Sen Chen, Ralph W. Pike: Computational Transport Phenomena for Engineering Analyses, USA, (2009).

[10] Massoud Kaviany: Essentials of Heat Heat Transfer, USA, (2011).

[11] J. Kohler, Numerical Calculation of the Distribution of Temperature and Heat Flux in Buses under the Influence of the Vehicle Air-conditioning System, ASHRAE Trans. 96 (1) (1990) 432–446.

[12] S. Mostafa Ghiaasiaan: Convective Heat and Mas Transfer, USA, (2011).
