Fabrication of Aluminum Clad Copper Tube by Planet Schràge Walzwerk Process

Abstract:

In the present paper, a fabrication process to roll-bonding aluminum clad copper tube(ACC) by Planet Schràge Walzwerk(PSW) has been introduced. Aluminum alloy(3003) as a outer tube layer and oxygen free copper(C12200) tube as a inner tube, were rolled to bond together using a PSW mill. Different specifications of ACC tube were selected to investigate the Al-Cu bonding layer thickness using scanning electronic microscope with EDX and bonding strength using peering test, and mechanical properties of ACC tube were also test. The experiment results indicated that Al-Cu composite layer is not only mechanical bonding but also metallurgical bonding with thickness of several micrometers. Moreover, tensile test indicated that the tensile strength of ACC was not less than 135 Mpa and elongation is about 35%, while peeling strength test showed that the two composite layers bond strength nearly arrived to 120 N/cm.

• Periodical: Advanced Materials Research (Volumes 602-604)
• Pages: 1855-1859
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.602-604.1855
• Online since: December 2012
• Authors: Xiao Li Zhang, Fu Sheng Tian
• Keywords: Aluminum Clad Copper Tube, Planet Schràge Walzwerk, Roll-Bonding

References

[1] G. Torres-Villasenor and J. Negrete-Sanchez. Aluminum clad zinc bimetallic planchet, Materials and Design, 2009, 29: 798-800.

DOI: 10.1016/j.matdes.2007.01.011

[2] V.L. A Silveria and A.G. Mury. Analysis of the behavior of the bimetallic joints(Al/Cu), Journal of Microstructure Science. 1987, 114: 277-287.

[3] K.Y. Rhee, W.Y. Han, H.J. Park, S.S. Kim. Fabrication of aluminum/copper clad composite using hot hydrostatic extrusion process and its material characteristics, Materials Science and Engineering A, 2004, 384: 70-76.

DOI: 10.1016/j.msea.2004.05.051

[4] N. Bay, Cold pressure welding; Characteristics, bonding mechanism, bond strength, Journal of Metal Constructure. 1986, 18(8): 369-372.

[5] Yeong-Maw Hwang, W.M. Tsai, F. H. Tsai, I. Her. Analytical and experimental study on the spiral marks of the rolled product during three-roll planetary rolling process, International Journal of Mechanic Tools & Manufacture, 2006, 46: 1555-1562.

DOI: 10.1016/j.ijmachtools.2005.09.013

[6] B. Li, S.H. Zhang, G.L. Zhang, H.Q. Zhang, Prediction of 3-D temperature field of TP2 copper tubes in three-roll planetary rolling process, Journal of materials processing technology, 2008, 205: 370-375.

DOI: 10.1016/j.jmatprotec.2007.11.213

[7] M. Abbasi, A. Karimi Taheri, M.T. Salehi. Growth rate of intermetallic compounds in Al/Cu bimetal produced by cold welding process.

DOI: 10.1016/s0925-8388(01)00872-6
