Numerical Simulation of Stamping Forming for an Automobile Reinforced Plate Based on Orthogonal Test

Abstract:

The effects of stamping process parameters (blank thickness, blank holder force, friction coefficient, die clearance) on the formability of an automobile reinforced plate were investigated. The process parameters are optimized based on the results of orthogonal testing. The optimal process parameters were obtained by simulation result analysis of variance. The accuracy of numerical simulation is verified by the experiment, which provides guidance for the actual production.

• Periodical: Advanced Materials Research (Volumes 602-604)
• Pages: 1899-1902
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.602-604.1899
• Online since: December 2012
• Authors: Ming Wei Wang, Long Chen, Xiu Jun Zhao, Shu Li
• Keywords: Automobile Reinforcing Plate, Numerical Simulation, Orthogonal Test, Stamping

References

[1] Xia Xiao-feng, Su Chuan-yi. in：Forging & Stamping Technology, 2006, 31(6):36-39

[2] Lan Feng-cong, Wang Yu-chao, Chen Jie-qing. in： Computer Integrated Manufacturing Systems, 2007, 13(8):1586-1596

[3] Peng Chen, Muammer Koc. Journal of Materials Processing Technology, 2007, 190:189-198.

[4] Carlos Gomes, Oladipo Onipede, Michael Lovell. Journal of Materials Processing Technology, 2005, 159:91-98

[5] Zhou Tai-an, Feng Yang, et al. Die & Mould Industry, 2009, 35(12):14-18

[6] Wang Tao, Tao Wei, et al. Forging & Stamping Technology, 2008, 33(5):48-50

[7] Chen Jie-qing, Wang Yu-chao, et al. Computer Integrated Manufacturing Systems, 2007, 13(12):2433-2440

[8] Li Yi, Li Huo-tu, et al. Forging & Stamping Technology, 2012, 37(2):21-24
