Safety Design of Wind Turbine’s Mobile Low Voltage Ride through Test Device

Abstract:

Wind turbine’s Low Voltage Ride Through(LVRT) ability must be verified by site-test, safety design was key factor of wind turbine’s mobile LVRT test device design and development. Based on research of protection scope, design principal of safety design, this paper realized five aspects of safety design: switchgear selection, relay configuration and setting value, routine operation, self-check failure lock, operation regulations. Safety design realized by this paper did not affect normal test process, colud provided perfect protection to operator, wind farm facilities and test device. Test device complied with this design had been used in wind turbine site-test and perfected well.

• Periodical: Advanced Materials Research (Volumes 608-609)
• Pages: 517-521
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.608-609.517
• Online since: December 2012
• Authors: Jin Ping Zhang, Rui Ming Wang, Qing Li, Yong Sun, Chen Chen
• Keywords: Low Voltage Ride through (LVRT), Safety Design, Wind Turbine (WT)

References

[1] Technical rule for connecting wind farm to power system. GB/T19963-2011．

[2] Bulletin of recent three accidents about wind turbine large scale separating from grid. Electric Power Supervision Committee Office, 2011.

[3] Study on Measurement Method of Wind Farm Integration to Grid, China Electric Power Research Institute, (2011)

[4] FD82B wind turbine low voltage ride through test report. China Electric Power Research Institute, (2011)

[5] Workshop on LVRT requirement and Testing Technology of Wind Turbines，China Electric Power Research Institute , (2007)

[6] DL/T 796-2001 Code on safety of wind farm.

[7] FGH Test Systems GmbH, "Mobile 10-40.5kV WEC LVRT Test Laboratory - Part 2:Measurement & Control Cabinet", 2009.

[8] FGH Test Systems GmbH, "Mobile 10-40.5kV WEC LVRT Test Laboratory - Part 3:LVRT Test Control System", 2009.

[9] ABB AG., "ZX 1.2 Gas-insulated medium voltage switchgear", (2009)

[10] DL/T 593-2006 Common specifications for high-vlotage switchgear and controlgear standards.

[11] DL/T 791-2001 Specification of indoor ac HV gas-filled switchgear panel.

[12] DL/T620-1997 Overvoltage protection and insulation coordination for AC electrical installations

[13] Wind turbine LVRT test system user manual. National energy Wind Power Integration Research and Evaluation Center, (2011)

[14] Wind turbine LVRT test system working tutorial manual. National energy Wind Power Integration Research and Evaluation Center, (2011)
