Low Voltage Ride-through Analysis and Control for Doubly Fed Wind-Power Induction Generator Using Finite State Machine Method

Abstract:

Low Voltage Ride through (LVRT) technology of Doubly Fed Wind-Power Induction Generator (DFIG) is a very important issue for grid-connection of wind power system. The paper analyzed and simulated dynamic response of DFIG under balanced and unbalanced gird voltage dip. Then proposed a whole set of LVRT control strategies based on finite state machine method for DFIG and carried out a detailed experimental validation on a 22KW DFIG driving system test platform on balanced grid voltage dip, which was connected to a voltage-dip generator. The experimental waveforms indicated that the proposed control strategy could effectively met LVRT requirement under different dip depth and time.

• Periodical: Advanced Materials Research (Volumes 608-609)
• Pages: 553-559
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.608-609.553
• Online since: December 2012
• Authors: Yun Wang, Wen Ming Gong, Xun Bo Fu
• Keywords: Double Fed Induction Generation (DFIG), Grid Voltage Dip, Low Voltage Ride through (LVRT), Wind Power

References

[1] PACS-L：SERC Office．China's Wind Power Development Survey Report[OL]．Beijing：State Electricity Regulatory Commission，2011． http://www.serc.gov.cn/jgyj/ztbg/201107/t20090721_11739.htm.

[2] PACS-L：Generator Fault Ride Through (FRT) Investigation [OL]．New Zealand，The National Grid，2009[2009-02]． http://www.electricitycommission.govt.nz/pdfs/opdev/comqual/windgen/ride-through/GEN-FRT-Stage1-Lit-review.pdf.

[3] Aoyang Han，Zhe Zhang，Xianggen Yin，et al．Study of the Factors Affected the Rotor Over-current of DFIG during the Three phase Voltage Dip[C]．Third International Conference on Electric Utility Deregulation and Restructuring and Power Technologies，Nanjing，China，2008．

DOI: 10.1109/drpt.2008.4523858

[4] Yang Shuying，Zhang Xing，Zhang Chongwei，et al．Electro-magnetic Transition of Doubly Fed Wind Turbines Initiated by Voltage Dip[J]．Automation of Electric Power Systems，2008，(19)：85-91 (in Chinese)．

[5] Lopez, J. Sanchis, P. Roboam, X. Marroyo, L．Dynamic Behavior of the Doubly Fed Induction Generator During Three-Phase Voltage Dips[J]．IEEE Transactions on Energy Conversion，2007，22(3)：709-717．

DOI: 10.1109/tec.2006.878241

[6] Anaya-Lara O, ZiFa Liu, Quinonez-Varela G, et al. Optimal DFIG Crowbar Resistor Design under Different Controllers during Grid Faults[C]. Third International Conference on Electric Utility Deregulation and Restructuring and Power Technologies, 2008: 2580-2585.

DOI: 10.1109/drpt.2008.4523846

[7] Joos G. Wind Turbine Generator Low Voltage Ride through Requirements and Solutions[C]. IEEE Power and Energy Society General Meeting, 2008: 1-7.

DOI: 10.1109/pes.2008.4596605

[8] Abdel-Baqi, O. Nasiri. A Dynamic LVRT Solution for Doubly-Fed Induction Generators [J]. IEEE Transactions on Power Electronics. 2010.25(1):193-196.

DOI: 10.1109/tpel.2009.2026578

[9] Jesús López, Eugenio Gubía, Eneko Olea, et al. Ride Through of Wind Turbines With Doubly Fed Induction Generator Under Symmetrical Voltage Dips [J]. IEEE Transactions on Industrial Electronics, 2009, 56(10): 4246-4254.

DOI: 10.1109/tie.2009.2028447

[10] Joos G．Wind Turbine Generator Low Voltage Ride through Requirements and Solutions[C]．IEEE Power and Energy Society General Meeting，Pittsburgh，Pennsylvania，UAS，2008．

DOI: 10.1109/pes.2008.4596605

[11] Wei Zhang，Peng Zhou，Yikang He．Analysis of the By-Pass Resistance of an Active Crowbar for Doubly-Fed Induction Generator Based Wind Turbines under Grid Faults[C]．International Conference on Electrical Machines and Systems，Wuhan，China，2008．

DOI: 10.1109/icems12746.2007.4412237

[12] Yun Wang, Dongli Zhao, Bin Zhao , Honghua Xu. Study on LVRT Technology of Doubly-fed Wind Power Generation System and Experimental Validation[C].ICEMS2010：588-592.
