A Dual-Processor Based Coordinator for Micro-Grid Control and Protection

Abstract:

With the development of micro-grid, the protection and control technologies for micro-grid have withdrawn broad attention. By analyzing the interactions between the micro-grid and the main grid, a dual-processor based coordinator is proposed in the paper. This coordinator achieves the functions of protection and control through two processors, utilizing the electrical information from the whole network, realizing the wide area data sharing and sound cooperation of the unit protection and regional control in the micro-grid. The proposed method enables smooth transition between grid-connected and islanded operation, which is adaptive to any operational modes. Implemented in a demonstrative project of the micro-grid in china, this novel method is verified to be efficient.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 1677-1684
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.1677
• Online since: December 2012
• Authors: Dong Liang Nan, Xiu Fan Le, Peng Peng Kang
• Keywords: Coordinator, DG, IEC61850, Microgrids (MGs), Protection and Control

References

[1] KANG Longyun, GUO Hongxia, WU Jie, et al. Distributed generation and effects of its parallel operation on power system [J]. Power System Technology, 2010, 34(11): 43-47(in Chinese).

[2] ZHAO Shanglin, WU Zaijun, HU Minqiang, et al. Thought about protection of distributed generation and microgrid [J]. Automation of Electric Power Systems, 2010, 34(1): 73-77(in Chinese).

[3] IEEE Std. 1547-2003 IEEE Standard for Interconnecting Distributed Resources with Electric [S]. New York: The Institute of Electrical and Electronics Engineers Inc, 2003.

[4] WANG Xiaoping, YU Yongyang, LI Yang. Design and implementation of microgrid protection systems [J]. Electric Power, 2011, 44(2): 78-81(in Chinese).

[5] PENG Mingzhi, ZHANG Wei, XIONG Zequn. Research and design of the grid-connected equipment of DG [J]. Power System Protection and Control, 2011, 39(14): 58-63(in Chinese).

[6] Nikkhajoei H, Lasseter H. Microgrid protection [C]//IEEE PES General Meeting. Tampa, Florida, USA: IEEE, 2007: 24-28.

DOI: 10.1109/pes.2007.385805

[7] N.Jayawama, X.Wut, Y.Zhangt, and ct a1. Stability of a MicroGrid [C]. The 3rd IET International Conference on Power Electronics, Machines and Drives, Ireland, 2006: 316-320.

[8] DING Ming, ZHANG Yingyuan, MAO Meiqin. Key technologies for microgrids being researched [J]. Power system technology, 2009, 33(11) (in Chinese).

DOI: 10.1109/supergen.2009.5348218

[9] IEC61850-9-2, Communication Networks and System in Substation—Part 9-2: Specific Communication Service Mapping (SCSM) —Sampled Values over ISO/IEC 8802-3 [S].

DOI: 10.3403/30145362

[10] IEC61850-8-1, Communication Networks and System in Substation—Part 8-1: Specific Communication Service Mapping (SCSM) —Mappings to MMS (ISO9506-1 and ISO 9506-2) and to ISO/IEC 8802-3 [S].

DOI: 10.3403/03074596
