Co-Combustion Mechanism Analysis of Oil Shale Semi-Coke and Rice Straws Blends

Abstract:

In this work, a series of combustion experiments for oil shale semi-coke , rice straws as well as their mixture were conducted by the thermogravimetric analyzer at different heating rates (10, 20 and 50 K/min) under atmospheric pressure. Combustion characteristic curves and combustion characteristic parameters were acquired. The results showed that the combustion process of blends can be broadly separated into three stages: combustion of the volatile matter, combustion of fixed carbon and combustion of difficult decomposition substance. The point of ignition and burnout shifted to higher temperature with increasing the heating rates. Furthermore, kinetics parameters were analyzed in the second stage. The result showed feasibility of using the reaction model to solve the kinetic parameters of biomass combustion. Finally, the obtained DTG curves were separated by Gaussian Fitting method. The result showed that the derivative thermogravimetry (DTG) curve displays an overlapping peak consisted of three sub-peaks at 645–900K under heating rate of 20K/min.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 45-48
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.45
• Online since: December 2012
• Authors: Qing Wang, Xu Dong Wang, Hong Peng Liu, Chun Xia Jia
• Keywords: Combustion Characteristic, Gaussian Fitting, Kinetic, Oil Shale, Rice Straws, Thermogravimetric Analysis (TGA)

References

[1] Q. Wang, W.Z. Zhao, H.P. Liu, C.X. Jia, S. H. Li: J. Applied. Energy. Vol. 88 (2011), p. (2080)

[2] Q. Wang, B.Z. Sun, X.H. Wu, J.R. Bai, J. Sun: J. oil. shale. Vol. 24 (2007), p.135

[3] H.P. Chen, B. Li, H.P. Yang: J. Industrial. Boiler. Vol. 5 (2009), p.1(in Chinese)

[4] R. Li, B.S. Jin, Z.P. Fu, F. X: J. Acta. Energ. Sol. Sin. Vol. 31 (2010), p.806 (in Chinese)

[5] B.Z. Sun, Q. Wang, P.Y. Shen, H.P. Liu, H. Qin, S.H. Li: J. Coal. Soc. Vol. 35 (2010), p.176 (in Chinese)

[6] Q.M. Yu, Y.J. Pang, H.G. Chen: J. Power. Vol. 7 (2001), p.9 (in Chinese)

[7] M. Varol, A.T. Atimtay, B. Bay: Investigation of co-combustion characteristics of low quality lignite coals and biomass with thermogravimetric analysis, edtied by Thermochimica. Acta Publising, (2010), in press

DOI: 10.1016/j.tca.2010.07.014

[8] Z.S. Yu, X.Q. Ma. , A. Liu: J. Biomass& Bioenergy. Vol. 32 (2008), p.1046

[9] A.W. Coats, J.P. Redfern: J. Nature. Vol. 201 (1964), p.68

[10] R.Z. Hu, S.L. Gao, F.Q. Zhao, et al: Thermal analysis kinetics, edtied by Beijing Science Press Publising, (2007), in press (in Chinese)

[11] G. Gregorc, G. Lightbody: J. Vol. 22 (2009), p.522
