2D CFD Simulation of Hydrodynamics of the Dense Zone of a 65t/h High-Low Bed CFB

Abstract:

Gas-solid flow behavior of the bottom zone of a 65t/h High-low bed CFB was simulated using the commercial computational fluid dynamics (CFD) software package Fluent. The Eulerian-Eulerian model (EEM) based on the kinetic theory of granular flow (KTGF) was adopted. This approach treated each phase as continuous separately. The link between the gas and solid phases was through drag model and turbulence model. While the turbulence was simulated by the standard k-ε and mixture multiphase model, the Gidaspow drag model was used to model the interphase interaction. Four phases were set to achieve size distribution in the EEM. Gas and solid flow profiles are obtained for solid velocity, solid volume fraction, pressure, and size distribution. The results show that EEM can predict preferably the internal circulation process of the dense zone high-low bed CFB.

You might also be interested in these eBooks

Advances in Power and Electrical Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 614-615)

Pages:

596-599

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.614-615.596

Citation:

Cite this paper

Online since:

December 2012

Authors:

Qing Wang, Jian Bo Xiao, Hong Peng Liu

Keywords:

Eulerian-Eulerian Model, High-Low Circulating Fluidized Bed, Internal Circulation Process

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Byung Ho Song, Young Tak Kim, Sang Done Kim: J. Chemical Engineering Journal. Vol. 68 (1997), p.115

Google Scholar

[2] Jin Hee Jeon, Sang Done Kim, Seung Jae Kim: J. Chemical Engineering and Processing. Vol. 47 (2008), p.2351

Google Scholar

[3] W. Namkung. et al: J. The Canadian Journal of Chemical Engineering. Vol. 78 (2000), p.1025

Google Scholar

[4] F. Yuqing, Tim Swenser-Simth, Peter J.Witt, Christian Doblin, Seng Lim, M.Phil Schwarz: J. Powder Technology. Vol. 219 (2012), p.78

Google Scholar

[5] Q.G. Wang. Numerical simulation of flow characteristics in High-low circulation fluidized bed, Harbin Institute of Technology. (2011) (in Chinese)

Google Scholar

[6] E. Hartge, L. Ratschow, R. Wischnewski, J. Werther: J. Particuology. Vol. 7 (2009), p.283

DOI: 10.1016/j.partic.2009.04.005

Google Scholar

[7] D. Gidaspow, Multiphase flow and fluidization, Academic Press, San Diego. (1994)

Google Scholar

[8] S. Ergun: J. Chem. Eng. Prog. Vol. 48 (1952), p.89

Google Scholar

[9] C. Wen, Y.H. Yu: J. Chemical Engineering Progress Symposium Series. Vol. 62 (1966), P. 100

Google Scholar

[10] P.C. Johnson, R. Jackson: J. Fluid Mech. Vol. 176 (1987), p.67

Google Scholar
