Microstructure of Mid and High Rank Coals from Qinshui Basin, North China and its Contribution to Coalbed Meathane

Abstract:

To better understand the relationship between micro-structures and coalbed methane(CBM), characterisation methods including microscopic photometer, scanning electron microscopy (SEM), mercury porosimetry, nitrogen adsorption at 77K and methane isothermal adsorption were introduced into investigating the adsorption capability of coal reservoir. The results reveal that the micropores volume has a increasing trend with increased vitrinite reflectance. The most favorable pore type is to have good connectivity, very good micro-pores porosity and good adsorption capability. Statistical analysis shows that endo-microfractures are the main type microfractures of Qinshui basin. Based on the results of coal macerals, coal lithotypes, it is found that the bright coal and telocollinites are favorable for endo-fractures formation. Obviously different from the formation of endo-microfracture, exo-microfracture strongly relates to the coal structure. A good match between the fractures and the pores is needed for a favorable CBM reservoir. Based on the evaluation of pore-fracture system, Yangquan is the second CBM commercial area of Qinshui basin.

• Periodical: Advanced Materials Research (Volumes 616-618)
• Pages: 201-207
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.616-618.201
• Online since: December 2012
• Authors: Zhi Hua Liu, Jun Gang Liu, Yi Guo Dong, Yang Chen, Li Ren Xing, Zhi Qiang Liu
• Keywords: Coalbed Methane (CBM), Coals, Fracture, Microstructure, Pores

References

[1] Y.D. Cai, D.M. Liu, Y.B. Yao, J.Q. Li and Y.Q. Qiu: International Journal of Coal Geology, Vol. 88(2011), p.101

[2] Maria M., Agnieszka D. and John R.: Energy & Fuels, Vol. 22(2008), p.4049

[3] Close, J.C.: AAPG Stud. Geol, Vol. 38(1993), p.119

[4] Gamson, P., D. Beamish, B.B. and Johnson, D.P. Fuel, Vol. 72(1993), p.87

[5] Hodot B.B.: Outburst of Coal and Coalbed Gas (China Industry Press, China 1966) (in Chinese)

[6] X.H. Fu, Y. Qin, W.H. Zhang, C.T. Wei and R.F. Zhou: Chinese Science Bulletin, Vol. 50(2005), p.66

[7] Y.B Yao, D.M. Liu, D.Z. Tang, S.H. Tang and W.H. Huang: Petroleum Exploration and Development, Vol. 34(2007), p.664 (in Chinese)

[8] X.M. Zhang: Coal seam methane in China (Shanxi Sciences and Technology Publish House, China 1991) (in Chinese)

[9] Law B E.: Coalbed Methane Symposium Proc (University of Alabama, Tuscaloosa 1993), p.435

[10] Y.B. Yao, D.M. Liu, D.Z. Tang, S.H. Tang and W.H Huang: Journal of China University of Mining & Technology, Vol. 39(2010), p.6 (in Chines)

[11] Y.B. Yao, D.M. Liu, W.H Huang, D.Z. Tang and S.H. Tang: Journal of China Coal Society, Vol. 31(2006), p.164 (in Chinese)

[12] Y.B. Yao, D.M. Liu and W.H. Huang: International Journal of Coal Geology, Vol. 88(2011), p.135

[13] Y.B. Yao and D.M. Liu: International Journal of Coal Geology, Vol. 96-97(2012), p.72
