Numerical Simulation of the Deep Mining of Phosphate Ore Body Based on Digital Image Processing

Abstract:

Based on digital image processing, use Matlab mathematical software to write Flac3D modeling interface program, and suppress noise transported from CAD software, for establishing numerical simulation model rapidly. With the No.59 exploration line profile picture of Yunnan Phosphate Group Jinning mine as the object of study, which is transformed from the open pit to deep underground mining, to establish Flac3D model mined with the way of room and pillar method study, it shows that: (1) using the method of multi-threshold segmentation, build the appropriate mask to suppress image noise effectively; (2) with controlling the horizontal grid cell size, achieve uniform mesh of the model; mesh at the strata border with the triangular grid, for weakening the jagged edges; (3) as the stopes excavated gradually, the movement extent of roof and floor is increasing influenced by mining; the roof is relatively stable, while the stress concentration factor of room pillars is bigger, therefore some measures should be taken to prevent the mine wall caving. The numerical simulation results provide a reference for the design feasibility study of phosphate mining and have a guiding significance for parameter optimization as well.

• Periodical: Advanced Materials Research (Volumes 616-618)
• Pages: 521-527
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.616-618.521
• Online since: December 2012
• Authors: Jun Wei Yao, Sheng Zhou Li, Ming Hui Li
• Keywords: Deep Mining of Phosphate, Digital Image Processing, FLAC^3D, Numerical Simulation

References

[1] Ding Xiuli1， LI Yaoxu，etal. Particle flow modeling mechanical properties of soil and rock mixtures based on digital image [J]. Chinese Journal of Rock Mechanics and Engineering，2010，29(3)：477-484.(In Chinese)

[2] Shao Longtan，Sun Yizhen，etal. Application of digital image processing technique to triaxial test in soil mechanics [J]. Rock and Soil Mechanics，2006，27(1)：29-34.(In Chinese)

[3] Chen Sha，Yue Zhongqi，Tan Guohuan. Digital image based numerical modeling method for heterogeneous geomaterials [J]. Chinese Journal of Geotechnical Engineering，2005，27(8)：956-964.(In Chinese)

[4] Chen Sha，Yue Zhongqi，Tan Guohuan. Actual mesostructure based three-dimensional numerical modeling method for heterogeneous geomaterials [J]. Chinese Journal of Rock Mechanics and Engineering，2006，25(10)：1951-1959.(In Chinese)

[5] Zhu zeqi， Xiao Peiwei， etal. Numerical simulation of fracture propagation of heterogeneous rock material based on digital image processing [J]. Rock and Soil Mechanics，2011，32(12)：3780-3786.(In Chinese)

[6] Xue Lei，Li Weichao，etal. Quasi-3D FLAC3D model generation based on pixel units of digital image [J]. Rock and Soil Mechanics，2010，31(6)：2001-2005.(In Chinese)

[7] Rafael C. Gonzalez，Richard E. Woods. Digital Image Processing [M]. Beijing：Pblishing house of electronics industry，2007.
