Dynamic Simulation Research on Three-Position Four-Way Reversing Valve

Abstract:

The reversing valve is a vital servo component in the hydraulic system, which reversing the movement of the execute component by the movement of the valve core to change on-off of the hydraulic channels. The model for a three-position four-way electromagnetic reversing valve used in some hydraulic system was established based on AMESim. The simulation operation results showed that the model had realized the same function with that of the actual valve, and had been consistent with the actual one on dynamic characteristics. The established of the model and the dynamic simulation analysis laid foundation for the hydraulic system operation reliably and effectively.

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 503-507
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.503
• Online since: December 2012
• Authors: Yu Lan Li, Xiang Bi An, Dao Wei Zhu
• Keywords: AMEsim, Reversing Valve, Simulation

References

[1] WANG Ji-nu, LI Tian-fu, DUAN Fang-liang and FEI Wang-long: Application Research on AMESim in Hydraulic Components, Hydraulics Pneumatics & Seals, Vol. 3(2011), pp.1-3.

[2] Luo Yanlei, Li Yuan, Li Meng and Bai Hua: Dynamic Simulation Research on Bi-position Three-way Valve Based on AMESim, Science Mosaic, Vol. 6(2010), pp.99-101.

[3] WU Yong, YANG Xi-jing, LIU Guang-zhi and QU Nai-rui: The Analysis and Simulation of Pressure Jump on Asymmetric Cylinder System Controlled by Symmetric Servo Valve, Hydraulics Pneumatics & Seals, Vol. 7(2011), pp.35-38.

[4] YIN Xiaoping, CAO Ming and LIU Yurong: Fault Simulation Study on Electrohydraulic Servo Valve, Machine Tool & Hydraulics, Vol. 9(2008), pp.125-126.

[5] LIU Xiaochu, YE Zhengmao, HAN Junwei and XIAO Lin: Modeling and Simulation of ________________________________________________________________________________________________________________________________135-136. )esearch on Bi-position model aulic, library of signal & controland __________________________Three-stage Electro-hydraulic Servo Valve Based on AMESim, Machine Tool & Hydraulics, Vol. 11(2008).
