Failure Analysis and Structure Improvement of Beam of Liner Vibrating Screen

Abstract:

Aiming at the frequently fracture happening in the large-scale liner vibrating screen beams, the software of finite-element analysis, ANSYS is used to analyze the modal and harmonic response of the beam structure. The analysis result suggests the danger area where beam is prone to fracture because of fatigue. The improvement scheme of the beam structure is proposed and a theoretical basis is provided for the same type of product design in the future. The failure form of the beam is fatigue failure. The maximum equivalent stress value of the improved beam structure comparing to the original design is decreased obviously, improving the stress state and the fatigue life and reliability of the liner vibrating screen.

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 69-73
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.69
• Online since: December 2012
• Authors: Cheng Long Li, Fan He, Ying Ying Zhang, Yang Gao, Peng Gao
• Keywords: Beam of Liner Vibrating Screen, Low Stress Failure, Model Analysis, Response Analysis

References

[1] Wen Bang-chun, Liu Shu-ying, etc. The Theory and Dynamic Design Method of Oscillating Machinery[M]. Beijing: Mechanical Industry Press, (2001).

[2] Zhang Ze-rong, Wang Yong-yan. Fatigue Life Analysis of Large-scale Liner Vibrating Screen[J]. Journal of Qingdao University of Science and Technology. Vol. 33, No. 1(2012), pp.74-77.

[3] He Fan, Fu Jia-xing, Su Rong-hua, etc. Dynamics Analysis of Beam Structure of Large-scale Liner Vibrating Screen[J]. World Sci-tech R & D, No. 1(2011), pp.221-223.

[4] Yin Jian-hong. Crack Reason Analysis of the Beam of Liner Vibrating Screen[J]. Coal Preparation Technology, No. 6(2004), pp.7-9.

[5] Wang Yong-yan, Mao Hui-qing, Zang Lin, etc. Stress Analysis and Model Modal Analysis of Large-scale Liner Vibrating Screen[J]. Coal Preparation Technology, No. 4(2010), pp.7-10.

[6] Liu Jin-feng, Lai Bin. Dynamical property Analysis of the Beam of Liner Vibrating Screen[J]. Mechanical Management and Development, Vol. 94, No. 1(2007), pp.71-72.

[7] Zhao Huan-shuai, Ding Wen-wen, Yang Xiuxiu. Simulation Analysis of the Beam Structure Fracture of the ZK3048 Liner Vibrating Screen[J]. Coal Science and Technology, Vol. 38, No. 7 (2010), pp.65-67.

[8] Wang Ran-feng, Qu Yao-We, Xiong Shibo. The Whole Vibrating Dynamic Kinetic Parameter Research Based on the Experimental Modal Analysis[J]. Coal Preparation Technology, No. 5(2003), pp.18-19.

[9] Li Wen-ying. Dynamics Analysis and the Dynamic Design of the Large-scale Vibrating Screen[D]. Taiyuan University of Technology, 2004. 3.

[10] CHANG E, DOVER W D. Weight function and stress intensity factor for a semi-elliptical surface crack in a tubular welded joint[J]. Journal of Strain Analysis for Engineering Design, Vol. 40, No. 4(2005), pp.301-326.

DOI: 10.1243/030932405x15972
