The Optimization of the Key Components of the Spinning Machine Conveyor System Based on ISIGHT

Abstract:

A transfer system in roving-spinning unit that establishes a connection between spindles of roving frame and spinning frame achieves the manipulations automatically in spinning workshop. We study that ISIGHT drive ANSYS to conduct integrated optimization of the key conveyor system components in this paper, the ANSYS-ISIGHT integration is successful. Before the optimal design, using the Latin method to design experiments. The experimental design can show the degree that the state variables and the target variables are affected by each input factor. The factor that has little impact on the results can be removed, thus the efficiency of the optimization can be improved. After the experimental design, using the multi-objective neural network to optimize the beam. Giving the beam safety conditions, including intensity, toughness, modal, stability. We optimize the structure base on security conditions, the volume of the beam in roving and yarn reservoir area has been largely decreased. Achieving the objectives of the lightweight design.

• Periodical: Advanced Materials Research (Volume 627)
• Pages: 466-470
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.627.466
• Online since: December 2012
• Authors: Bin Lin, Xu Zhang, Xiao Gang Liu
• Keywords: ISIGHT-ANSYS Integration, Latin Method, Multi-Objective Genetic Algorithm, Optimization Iterations

References

[1] P. Wang: Design, Process Optimization and Control of Injection Molding Based on CAE (MS., Zhenzhou University, China 2003), pp.12-16

[2] Y.K. Sui: Modeling, Transformation and Optimization: New Development of Structural Synthesis Method (Dalian University of Technology Press, 1996).

[3] W.Y. Shang, S.M. Li and Q.Y. Bao: Mechanical Science and Technology, Vol. 28 (2009) No. 7, pp.881-885. (In Chinese)

[4] K. Cheng: CAE Analysis Method Research of Complex Mechanism (MS., Tianjin University, China 2007), pp.4-6,17-25. (In Chinese)

[5] Z.Q. Cui, R.F. Yang: Chinese Journal of Mechanical Engineering, Vol. 44 (2008) No. 2, pp.234-237, (In Chinese)

[6] Instructions for Conveyor System between Roving Frame and Spinning Frame from Tianjin Textile Machinery Factory. (In Chinese)
