Ring-Space Array Torque Measure System and Signal Singularity Detection

Abstract:

Torque is the most important dynamic characteristics of the mechanically-driven system. In order to monitor the mechanical principal axis in real time, a new non-contact torque measurement system based on ring-space array sensor is proposed. This system can be used for the analysis of dynamic characteristics of the mechanical system’s axis under various loads and hard working environments. Singularity in the collected signals is most important with the mechanical system. Because of much noise was contained in collected signals, which always interferes the signal’s singularity detection. According to the different behaves of signal and noise under wavelet transform, a method with wavelet filtering and singularity detection combined is proposed. This method could realize two-dimension filtering reconstruction in both time and frequency domain, in which the singularity information in signal can be kept well while the noise will be filtered. The proposed method is suitable for singularity detection of signals under serious noise.

• Periodical: Advanced Materials Research (Volume 629)
• Pages: 741-746
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.629.741
• Online since: December 2012
• Authors: Yuan Gan Wang
• Keywords: Ring-Space Array Sensor, Singularity Detection, Torque Measurement, Wavelet Transform (WT)

References

[1] Kakinoki Tetsuro, Yokoyama Ryuichi, Fujita Goro. Shaft torque observer and excitation control for turbine–generator torsional oscillation. Electric Power Systems Research, 2004(68)3: 248~257.

DOI: 10.1016/j.epsr.2003.06.007

[2] WANG Yuan-gan, YU Hong-lin, HE An-guo1, BA Jun1, CHEN Zhuo. Design and principle analysis of the ring-space array torque sensor. Transducer and Micro-system Technologies, 2011, 30(6): 49-52.

[3] Nakonieczny K. Entropy generation in a diesel engine turbocharging system. Energy, 2002, 27(11): 1027~1056.

DOI: 10.1016/s0360-5442(02)00082-8

[4] WANG Yuan-gan, YU Hong-lin, BA Jun. Research on torque sensor measurement system used ring-space array. Transducer and Micro-system Technologies, 2010, 29(9): 33-36.

[5] Chen Y G, Tian Z P, Miao, Zh Q. Detection of singularities in the pressure fluctuations of circulating fluidized beds based on wavelet modulus maximum method. Chemical Engineering Science, 2004, 59(17): 3569~3575.

DOI: 10.1016/j.ces.2004.06.001

[6] Sánchez-ávila, C. Wavelet domain signal deconvolution with singularity preserving regularization. Mathematics and Computers in Simulation, 2003, 61(3): 165~176.

DOI: 10.1016/s0378-4754(02)00073-3

[7] Leporini, D, Pesquet J C. Bayesian wavelet denoising: Besov priors and non-Gaussian noises. Signal Processing, 2001, 81(1): 55-67.

DOI: 10.1016/s0165-1684(00)00190-0
