A Novel Generator Side Converter Control Scheme of Direct Driven PMSG Wind Turbine

Abstract:

With the advance of electronic technology,the filed-oriented control of voltage space vector PWM have become more efficient in generator side converter control.This paper presented the direct driven wind turbine model and the permanent magnet synchronous generator (PMSG) model in synchronous rotating d-q reference frame.Using filed-oriented control of voltage space vector PWM in generator side converter control for enhance efficiency. The optimal control strategy can keep wind turbine working at optimal tip speed ratio for capture maximum wind power.A novel nonlinear PI controller for anti-windup implemented in control loop for highest efficiency of wind turbine which can be reached.Simulation results verified and shown via Matlab/Simulink that the performance of nonlinear PI controller for anti-windup in generator side converter control system is better than traditional PI controller in control loop for wind turbines.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 1095-1100
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.1095
• Online since: January 2013
• Authors: Yang Shun, Li Da Zhang
• Keywords: Nonlinear PI Controller for Anti-Windup, Optimal Control, Permanent Magnet Synchronous Generator (PMSG), SVPWM, Wind Turbine (WT)

References

[1] M. Ying,G. Li, M. Zhou, and C. Zhao, Modeling of the wind turbine with a permanent magnet synchronous generator for integration, IEEE, p.1–6. ISBN 1-4244-1298-6, (2007).

DOI: 10.1109/pes.2007.385982

[2] H. Polinder,F. F. A. van der Pijl, G. J. de Vilder, P. J. Tavner. Comparison of direct-drive and geared generator concepts for wind turbines, IEEE Trans. on energy conversion, vol . 21, no. 3, pp.725-733, (2006).

DOI: 10.1109/tec.2006.875476

[3] Ye Zhihang, Wind Turbine Control Technology, Beijing, Mechanical Industry Publishing Press. (2006).

[4] H. Battista,R. Mantz, Dynamical variable structure controller for power regulation of wind energy conversion systems, IEEE Trans. Energy Conversion, vol. 19, no. 4, pp.756-763, (2004).

DOI: 10.1109/tec.2004.827705

[5] S. Li,T. Haskew, Characteristic study of direct driven PMSG wind turbine under general dq control strategies, in: Proceedings of the 2008 IEEE PES (Power &Energy Society) General Meeting, Pittsburgh, PA, July 21–24, (2008).

DOI: 10.1109/pes.2008.4596191

[6] K. Tan,S. Islam, Optimum Control Strategies in Energy Conversion of PMSG Wind Turbine System without Mechanical Sensors, IEEE Trans. Energy conversion . Vol. 19, No. 2, (2004).

DOI: 10.1109/tec.2004.827038

[7] Wang Youqing, General PI control algorithm of PLC, Industrial Control and Instrumentation, 2003(1): 46-48.

[8] Raiambal K, Chellamuthu C, Modeling and simulation of grid connected wind electric genera ting system. In: TENCON 2002, IEE E region 10 conference on computers, communications. China, vol . 3. Beijing: Control and Power Engineering; October 2002. p.1847.

DOI: 10.1109/tencon.2002.1182696

[9] M. Chinchilla, S. Amaltes, and J.C. Burgos, Control of permanent-magnet generators applied to variable-speed wind-energy systems connected to the grid, IEEE Trans. Energy Conversion, Vol. 21, No. 1, p.130 – 35, (2006).

DOI: 10.1109/tec.2005.853735

[10] V. H. Casanova and L. L. Freris, Dynamic and control of wind energy conversion system, in Proc. 5th Congr. Brasileiro de Automatica , Campina Grande, Brazil, (1984).
