Instantaneous Frequency Estimation of Ultrasonic Testing Signal Based on Matching Pursuits

Abstract:

The differences of instantaneous frequency (IF) characteristics between the defect echo and the noise can be used to detect defect and suppress noise for ultrasonic testing signal. Therefore, the IF is one of the important instantaneous parameters of ultrasonic testing signal. To estimate the IF of ultrasonic testing signals more effectively, the peak of time-frequency representation (TFR) from matching pursuits (MP) decomposition is proposed. The performances of IF estimators are compared on the simulated signals at different signal-to-noise ratio (SNR) and the real ultrasonic testing signal. The simulation results present that the proposed method can estimate accurate IF at different SNR.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 1367-1372
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.1367
• Online since: January 2013
• Authors: Xiu Li Du
• Keywords: Instantaneous Frequency, Matching Pursuits, Peak, Time-Frequency, Ultrasonic Testing (UT)

References

[1] M. Angel, R. Hernandez, Ultrasonic Non-Destructive Evaluation with Spatial Combination of Wigner-Ville Transforms, NDT&E International, 6(2003)441-445.

DOI: 10.1016/s0963-8695(03)00033-1

[2] S. Pavlopoulou, W.J. Staszewski, C. Soutis, G. Manson, Analysis of instantaneous characteristics of guided ultrasonic waves in metallic structures with aluminum repair patches, Proceedings of SPIE-The International Society for Optical Engineering, San Diego, (2011).

DOI: 10.1117/12.886187

[3] M.F. Ghazali, S.B.M. Beck, J.D. Shucksmith, J.B. Boxall, W.J. Staszewski, Comparative study of instantaneous frequency based methods for leak detection in pipeline networks, Mechanical Systems and Signal Processing, 29(2012)187-200.

DOI: 10.1016/j.ymssp.2011.10.011

[4] S. Mallat, Z. Zhang, Matching Pursuits with Time-Frequency Dictionaries, IEEE Transaction on Signal Processing, 2(1993)3397-3414.

DOI: 10.1109/78.258082

[5] H. Zakria, S.T. John, R.H. David, D. Charanpal, Design and generalization analysis of orthogonal matching pursuit algorithms, IEEE Transactions on Information Theory, 8(2011) 5326-5341.

DOI: 10.1109/tit.2011.2158880

[6] C.T. Tony, W. Lie, Orthogonal matching pursuit for sparse signal recovery with noise, IEEE Transactions on Information Theory, 7(2011)4680-4688.

DOI: 10.1109/tit.2011.2146090

[7] M. Paolo, A. Finn, V. Michel, A matching pursuit algorithm approach to chaser-target formation flying problems, IEEE Transactions on Control Systems Technology, 2(2012) 513-519.

DOI: 10.1109/tcst.2011.2130526

[8] M. Etai, A. Amnon, A. Mayer, A matching pursuit method for approximating overlapping ultrasonic echoes, EEE Transactions on Ultrasonics, Ferroelectrics, and Frequency Control, 9(2010) 1996-(2004).

DOI: 10.1109/tuffc.2010.1647

[9] R. Demirli, Model-based estimation pursuit for sparse decomposition of ultrasonic echoes, IET Signal Processing, 4(2012) 313-325.

DOI: 10.1049/iet-spr.2011.0093

[10] B. Boashash, Estimating and Interpreting the Instantaneous Frequency of a Signal-Part 2: Algorithms and Applications. Proceedings of IEEE, 4(1992)520-538.

DOI: 10.1109/5.135376

[11] R. Demirli, Model Based Esteimation of Ultrasonic Echoes-Analysis-Part 1: Algorithms and Applications, Illinois Institute of Technology, 48(2001)787-802.

[12] X.L. Du, Y. Shen, Y. Wang, Z.D. Xu, Ultrasonic flaw detection based on entropy of instantaneous frequency, China Mechanical Engineering, 18(2006)1899-(1902).
