Research on Simulation of Cutting Process Based on the Finite Element Analysis Method

Abstract:

With the rapid penetration of information technology in various fields, CAD/CAM/CAE technology has been widely used to fundamentally change the traditional design, production, organizational models, it also has a very important significance to promote the technological transformation of existing enterprises, bring the whole structural change of the night, develop the new technologies and the promotion of economic growth. The paper uses the blades of steam turbine as an example, combined with the finite element analysis method to study the whole cutting process, the whole process was simulated and the results of error were had analysis and optimization.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 686-690
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.686
• Online since: January 2013
• Authors: Yi Li Shen
• Keywords: Error Analysis, Finite Element Analysis (FEA), Milling, Simulation, Turbine Blade
