Simulation Study of a Novel Controllable Metamorphic Palletizing Robot Mechanism

Abstract:

The palletizing robot mechanism was investigated in this paper. The concepts of the metamorphic mechanism and controllable mechanism were introduced into the design of palletizing robot mechanism, a novel controllable metamorphic palletizing robot mechanism with geometric limit, which can achieve a variety of flexible action, was designed. The working space of output of the controllable metamorphic palletizing robot mechanism was obtained through simulation study, and the kinematics characteristics of the mechanism were analyzed. The work of this paper provides some references for the practical application of such kind of mechanism in the palletizing robot.

• Periodical: Advanced Materials Research (Volumes 634-638)
• Pages: 3788-3793
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.634-638.3788
• Online since: January 2013
• Authors: Ru Gui Wang, Hua Qiang Yuan, Guang Lin Shi, Hui Qing Chen, Ye Xun Li, Qing Ming Zou
• Keywords: Kinematics Analysis, Metamorphic Mechanism, Palletizing Robot, Simulation Study, Working Space
