Analysis of Nonlinear Buckling of a Long-Span Elliptic Paraboloid Suspended Dome Structure

Abstract:

The suspended dome structure, which is a new kind of hybrid spatial one composed of the upper single layer latticed shell and the lower cable-strut system, generally has smaller rise-to-span ratio, thus the overall stability is one of the key factors to the design of the structure. The nonlinear buckling behavior of an elliptic paraboloid suspended dome structure of span 110m80m is investigated by introducing geometric nonlinearity, initial geometric imperfection, material elastic-plasticity and half-span distribution of live loads. The study shows that the coefficient of stable bearing capacity usually is not minimal when the initial geometric imperfection configuration is taken as the first order buckling mode. The unsymmetrical loading distribution and the material nonlinearity might have significant effects on the coefficient. The structure is sensitive to the changes of initial geometric imperfection, and the consistent mode imperfection method is not fully applicable to the stability analysis of suspended dome structure.

• Periodical: Advanced Materials Research (Volumes 639-640)
• Pages: 191-197
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.639-640.191
• Online since: January 2013
• Authors: Zheng Rong Jiang, Kai Rong Shi, Xiao Nan Gao, Qing Jun Chen
• Keywords: Elliptic Paraboloid, Initial Geometric Imperfection, Nonlinear Buckling, Suspended Dome

References

[1] K.R. Shi, Theoretical Analysis and Construction Study on Long-span Elliptical Suspendome Structures, Southeast University, Nanjing, 2007.

[2] S.Z. Shen, X. Chen, Stability of Latticed Shells, Science Press, Beijing, 1999.

[3] JGJ 7-2010 Technical Specification for Space Frame Structures, China Architecture & Building Press, Beijing, 2010.

[4] A.L. Zhang, X.C. Liu, Suspen-dome optimal design of Olympic Badminton Stadium based on integral stability, Building Structure. 37 (2007) 1-5.

[5] J.Q. Ge, G.J. Zhang, S. Wang, et al, The overall stability analysis of the suspend-dome structure system of the badminton gymnasium for 2008 Olympic Games, Journal of Building Structures. 28 (2007) 22-30, 44.

[6] A.L. Zhang, X.F. Zhang, J.Q. Ge, et al, Influence of initial geometrical imperfections on stability of a suspendome for badminton arena for 2008 Olympic Games, Spatial Structures. 12 (2006) 8-12.

[7] Z.R. Jiang, K.R. Shi, M. Xu, J. Cai, Analysis of nonlinear buckling and construction simulation for an elliptic paraboloid radial beam string structure, China Civil Engineering Journal. 44 (2011) 1-8.

[8] GB 50205-2001 Code for Acceptance of Construction Quality of Steel Structures, China Planning Press, Beijing, 2001.
