Numerical Analysis of Anchor Reinforced Length Effect on Highway Slope

Abstract:

Based on the strength reduction method，the anchor reinforced slope has been simulated by elastic-plastic FEM. The safety factor of reinforced slope with anchor was gotten by heuristic search method. The plastic zone running through or not is taken as a standard to solve slope safety factor. The research results show better the distribution situation of stress and strain in slope. It proposes a new method to evaluate the stability of slope with complex boundary conditions. Taking a slope engineering for example, the stability safety coefficients of the slope are calculated when the slope is reinforced with anchors of different length. When the design length of anchor is longer than a certain value, the anchor length has little effect on improving the stability of slope and slope toe. Consequently, the reasonable design length of anchor is put forward

• Periodical: Advanced Materials Research (Volumes 639-640)
• Pages: 602-607
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.639-640.602
• Online since: January 2013
• Authors: Jing Rong Zou
• Keywords: Finite Element Analysis (FEA), Reinforcement Mechanism, Slope Stability, Strength Reduction Method

References

[1] Z. Y. Chen. A three-dimensional slope stability analysis method using the upper bound theorem(I):theory and methods, International Journal of Rock Mechanics ＆ Mining Sciences. 38(2001) 369-378.

DOI: 10.1016/s1365-1609(01)00012-0

[2] Z. Y. Chen, H. L. Mi , X. G. Wang. Slope stability analysis of three dimensional limit equilibrium method, Journal of Geotechnical Engineering. 23(2001) 525-529.

[3] J. M. Duncan . State of the art: Limit equilibrium and finite-element analysis of slope, Journal of Geotechnical Engineering, ASCE. 122(1996) 577-596.

DOI: 10.1061/(asce)0733-9410(1996)122:7(577)

[4] G. C. Xu , Y. R. Zheng. Geotechnical engineering application yield criterion, Journal of Geotechnical Engineering. 12(1990) 93-99.

[5] S. Y. Zhao , Y. R. Zheng. With finite element strength reduction for slope stability safety coefficient, Journal of geotechnical engineering. 24(2002) 343-346.

[6] S. Y. Zhao, Y. R. Zheng, Y. F. Zhang. Limit finite element method of the lecture-ⅡFinite element strength reduction of stability criterion of slope in discussion, Journal of Geotechnical Engineering. 26(2005) 332-336.

[7] J. L. Liu, M.T. Luan, S. F. Zhao, etal. About strength reduction in finite element method, the slope instability criterion of discussion, Journal of Geotechnical Engineering. 26(2005) 1345-1348.
