Engineered Wood in Cold Climate - Application to Monitoring of a New Swedish Suspension Bridge

Abstract:

Engineered wood is increasingly used in large structures in Europe, though little is known of its behavior in cold climate. This paper presents the structural health monitoring (SHM) system of a newly built suspension bridge with a deck of glulam timber as well as a bond stability study regarding cold climate performance of engineered wood. The bridge is located in Skellefteå in northern Sweden, and it connects two parts of the city situated on opposite shores of the Skellefteå river. In this ongoing study of the timber-bridge, a structural health monitoring system is employed to verify structural design and long-term performance. This 130m-span bridge is monitored using GNSS receivers, MEMS accelerometers, laser positioning systems, wireless moisture content sensors, strain gauges and weather stations. Data from the monitoring systems is analyzed regarding accuracy, complexity, costs and reliability for long time use. Engineered wood application in bridges, sports centers and timber buildings are discussed. Bond stability of glulam structures in cold climate is also examined in a range of experiments ranging from small glued wood joints to full size glulam bridge performance over time. From an engineered wood material point of view, the study is relevant to cold regions such as Scandinavia, Canada, Alaska, Russia, and the northern parts of China and Japan etc. The engineered wood constructions in these areas will be exposed to low temperature in a quite long period each year. The goal is to determine how engineered wood behaves when exposed to temperatures between 20 °C to -60 °C.

• Periodical: Advanced Materials Research (Volumes 639-640)
• Pages: 96-104
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.639-640.96
• Online since: January 2013
• Authors: Xiao Dong Wang, Olle Hagman, Niclas Björngrim, Lennart Elfgren
• Keywords: Cold Climate, Engineered Wood, Global Navigation Satellite System (GNSS), Glu Bond Stability, MEMS, Structural Health Monitoring (SHM), Timber-Bridge

References

[1] Clauss S., Joscak M., Niemz P. (2011): Thermal stability of glued wood joints measured by shear tests. European Journal of Wood and Wood Products 69(2011): 101-111.

DOI: 10.1007/s00107-010-0411-4

[2] Falkner H, Teutsch M (2006): Load-carrying capacity of glued laminated wood girders under temperature influence. Bautechnik 83(6): 391-393.

[3] Frangi A, Fontana A, Mischler A (2004): Shear behavior of bond lines in glued laminated timber beams at high temperatures. Wood Sci. Technol 38(2): 119-126.

DOI: 10.1007/s00226-004-0223-y

[4] Gustafsson, A., Pousette, A., and Björngrim, N., (2010).

[5] Handa, K., (1998). Calculation of natural frequencies and damping for Waxholm Timber Bridges. Unpublished report.

[6] Karoumi, R., (2001): Vibrationsmätning på Waxholms träbro, resultatjämförelse med mätningar från 1996. Stockholm: Royal Institute of Technology, Structural Engineering and Bridges, Technical Report 2001: 06, ISSN 1404-8450.

[7] Pousette, A., (1999): Cable-Stayed Timber Bridges. Nordic Timber Bridges Project, phase 2. Nordic Timber Council.

[8] Pousette, A., (2008): Träbroar – Konstruktion och dimensionering. (Wood Bridges – Construction and Design). Borås: SP Report 2008: 50, 113 pp. ISBN 978-91-85829-73-6.

[9] Vaisala Wheather Sensors (2010): http: /www. vaisala. com/en/products/multiweathersensors/Pages/WXT520. aspx.

[10] Roberts, G. W., Meng, X., and Dodson, A. H., (2001).

[11] Posette, A. and Sandberg, K (2007).

[12] He, G. J.; Bennitz, A.; Enochsson, O.; Elfgren, L.; Paulsson, B.; Töyrä, B.; Olofsson, P.; Kronborg, A. (2006).

[13] He, G.; Zou, Z.; Enochsson, O.; Bennitz, A.; Elfgren, L., Kronborg, A.; Töyrä, B. & Paulsson, B. (2008).

[14] Zou, Z., Enochsson, O., He, G., & Elfgren, L. (2009).

[15] Sabourova, N., Grip, N., Puurula, A., Enochsson, O., Tu, Y., Ohlsson, U., Nilsson, M., Elfgren, L., & Carolin, A. & (2012).

[16] Sustainable Bridges (2008).

[17] MAINLINE (2011).

[18] Jonasson, J. -E.; Emborg, M.; Elfgren, L. & Wallin, K. (2009).
