A New Numerical Simulation Model for Shrinkage Defect during Squeeze Casting Solidification Process

Abstract:

In this paper, according to the characteristics of squeeze casting solidification process, the calculation model (FDM format) of the partial differential equations with high thermal conductivity is used to the numerical simulation of temperature field. Dynamic isolated multi-molten pool judgment method is used to determine the position of the pool and FEM is used to calculate the pressure of pool center. If the pressure of molten pool center has been down to 0, the liquid metal closed in the scale will be solidification under the condition of no pressure, and will shrinkage based on the way of gravity shrinkage. The equivalent liquid surface descending method of isolated molten pool is used to predict the formation of shrinkage defect; the simulation result is coinciding with experimental data.

• Periodical: Advanced Materials Research (Volumes 641-642)
• Pages: 309-314
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.641-642.309
• Online since: January 2013
• Authors: Hua Hou, Hong Hao Ge, Yu Hong Zhao, Wei Ming Yang
• Keywords: Casting Shrinkage Defect, FDM/FEM, Simulation, Squeeze Casting

References

[1] LUO Shou-jing, in: Liquid die forging and squeeze casting technology, edited by Chemical industry publication, Beijing, (2006), in press.

[2] SHENG Long-hua, etc. The liquid metal forming mechanism of the die casting crowded hang discussed ,J. Special casting and non-ferrous alloy Vol. 29 (4) (2009) pp.340-342.

[3] LUO Shou-jing, etc. Production of motorcycle brake clamp body by squeezing casting, J. Special casting and non-ferrous alloy Vol. 30(3) (2010) pp.234-237.

[4] LUO Shou-jing, etc. Research on squeeze casting technology for motorcycle clamp bodies, J. Foundry technology Vol. 31 (5) (2010) pp.620-624.

[5] ZHANG Ming, ZHANG Wei-wen, ZHAO Hai-dong etc. Effect of pressure on microstructures and mechanical properties of Al-Cu-based alloy prepared by squeeze casting, J. Transactions of Nonferrous Metals Society of China Vol. 17 (3) (2007) pp.496-501.

DOI: 10.1016/s1003-6326(07)60122-8

[6] HAN Zhi-qiang, etc. Thermo mechanical modeling of solidification process of squeeze casting. (Ⅰ) , J. Acta Metall Sinica Vol. 45 (3) (2009) pp.356-362.

[7] ZHU Wei, etc. Thermo mechanical modeling of solidification process of squeeze casting (Ⅱ), J. Acta Metall Sinica, Vol. 45 (3) (2009) pp.363-368.

[8] LIAO Dun-ming, etc. Casting hot stress field numerical simulation, J. Special casting and non-ferrous alloy Vol. (6) (2003) pp.30-32.

[9] LI De-long, etc. Stress field simulation of ZA27 alloy casting with larger ratio of height to diameter during squeeze cast, J. Shenyang university journal Vol. 27 (2) (2003) pp.138-142.
