Study on Calculations of Geometric Dimensions and Modification Coefficients of Planetary Gear Reducer of Less Tooth Difference with Biasing Crankshaft Based on Matlab

Abstract:

Different formula characteristics of internal gear pair with few teeth difference of planetary gear reducer with biasing crankshaft were compared, and the restricted conditions satisfied by them when meshing were set forth. On this basis, the relationships of modification coefficients, tooth addendum coefficient and the center distance were studied, the optimal choice method for modification coefficient based on matlab for the smallest meshing angle was proposed, and verified with living example, at the same time the effect of the different step lengths on calculation results was researched. The results showed that the optimum method is accurate, and avoids the disadvantages of the other optimal choice methods.

• Periodical: Advanced Materials Research (Volume 644)
• Pages: 298-303
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.644.298
• Online since: January 2013
• Authors: Qiang Xu, Qi Sheng Xu, Dao Yi Xu
• Keywords: Biasing Crankshaft, Modification Coefficient, Planetary Gear Reducer, Profile Overlap Interference, Tooth Addendum Coefficient

References

[1] Zhu Zeng, Jia-fei YE, The Optimization Design of the Planetary Gear Reducer of Small Tooth Difference [J], Manufacturing Automation, 2011, 33(1): 218~220.

[2] Yu Yue-hai, Zhang Ce, A Cad System of Geometric Design for Internal Gear Pair and Its Application to the Design of Three-Ring Gear Reducers[J], Mechanical Science and Technology, 2005, 24(4): 475~478

[3] Yong-shen Liang, Hua-min Li, Gui-xian Li, The Modification Coefficient Ensurance of Few Teeth Difference Internal Gear Pair Cutting with Cutter[J], Journal Institute of Technology, 1999, 31(4): 34~39.

[4] Gen-qun Cui, Chun-shu Li, Establishment of Optimization Mathematic Model for Less Tooth Differenced Planetary Transmission Mechanism with Biasing Crankshaft[J], Journal of Machine Design, 2005, 22(2): 37~39.

[5] Zi-qiang Zhao, Chun-lin Zhang, Ai-ming Chen, Design of Distributary Interior Translation Gear Transmission Mechanism[J], Journal of Machine Design, 2008,25(9): 41~44.

[6] Zi-qiang Zhao, Ai-ming Chen, Chun-lin Zhang, Transmission Principle of Power Diffluence Internal Parallel of Moving Gears[J], Water Conservancy & Electric Power Machinery, 2007,29(9): 22~25.

[7] Xiao-long Liu, Hongbo Huang, Disscussion on Caculating the Geometric Dimension of the Internal Gear[J], Journal of Mechanical Transmission, 2008, 32(5): 99~102.

[8] Guang-jian Wang, Han-jun Jiang, Zhi-gang Chu, Geometric Design of Involute Internal Gear Pair with Few Teeth Difference[J], Transaction of the Chinese Society for Agriculture Machinery, 2011(4): 201~205.

[9] Fan Yang, shi-Jie Wang, Method of Selecting Modification Coefficient of Involute Internal Gear with Zero-Tooth-Difference Mechanism[J], Journal of Senyang University of Technology, 2004(6): 623~625.

[10] Li-hua Zhang, Yan Zeng, The new Handbook of Mechanical Design[M]，Posts & Telecom Press, 2008.

[11] Li-min Wang, The Optimization Design of The Planetary Gear Reducer of Small Tooth Difference with the Blasting Crank Shaft[D], Tianjing: Hebei University of Technology, 2005:40~47.
