Earthquake Response Analysis and Safety Evaluation of Haokou Gravity Dam

Abstract:

According to the actual engineering conditions of Haokou RCC Gravity Dam, the 3-D FEM model of the typical overflow dam section and its foundation is set up. Using the response spectrum method, the responses of earthquake acceleration, displacement and stress of the dam and their distribution laws were studied under the seismic loading, and the anti-sliding stability of dam is also analyzed. The calculation results show that under the design earthquake condition, the maximum principle stress response of dam body is 2.26MPa, which appears at the dam heel. The safety factor of stability against sliding on the face of the dam foundation is 1.43 and the stability against deep sliding is 3.2. So this dam section can meet the strength and stability requirements of standard, its earthquake-resistant safety could meet the requirements of standard.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 1394-1398
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.1394
• Online since: March 2013
• Authors: Fan Yang, Zhen Zhong Shen, Kai Min Chu, Xi Yao Zhao
• Keywords: Anti-Sliding Stability, Earthquake Response, Finite Element Method (FEM), Gravity Dam, Response Spectrum Method

References

[1] Tengjiao Zhang, Zhenzhong Shen, Liang Liang, et al. Earthquake-resistance Safety Evaluation of Non-overflow Section of Haokou Concrete Gravity Dam [J]. South-to-North Water Transfers and Water Science & Technology. 2012, 10(6), 9~13. (In Chinese).

[2] Zhenzhong Shen, Yan Wang, Jin Jia, et al. Seismic Response Analysis of Madushan Gravity Dam by Using 3D FEM [J]. WATER POWER，2009, 35(5): 43~45. (In Chinese).

[3] Gao Lin, Jianyun Chen. Concrete Dam Seismic Safety Evaluation [J]. Journal of Hydraulic Engineering, 2001, (2) : 8~15. (In Chinese).

[4] DL 5073-2000, Specification for Seismic Design of the Hydraulic Structures [S]. Beijing: China electric power press, 2000. (In Chinese).

[5] Ganchen Gu. Embankment Dam on Earthquake Engineering [M]. Nanjing: Hohai University Press, 1989. (In Chinese).

[6] Bin Pei. Comparative Analysis of Seismic Dynamic Response of Hardfill Dam [J]. Water Resources and Power, 20l0, 28(2): 85~88. (In Chinese).

[7] Lei Gan, Zhenzhong Shen, Chunhai Ling, et al. Madushan Gravity Dynamic Response Analysis and Safety Evaluation [J]. Water Resources and Power, 2010, 28(7): 78~81. (In Chinese).

[8] DL5108-1999. Design specification for concrete gravity dams [S]. Beijing: China electric power press, 2000. (In Chinese).

[9] Yisheng Huang, Jianlin Li, Xiaolin Chang. Seismic Safety Evaluation of Gravity Dam Based on the Mode-decomposition Response Spectrum Method [J]. Journal of China Three Gorges University, 2010, ( 6) : 11~16. (In Chinese).

[10] Yan Wang, Zhenzhong Shen, Yifen Li. Stress Deformation and Strength Reserve Coefficient Analysis On Overflow Section of Madushan Gravity Dam [J]. Water Resources and Power, 2009, 27(2)：100~103. (In Chinese).
