Research on Load Distribution Effect of Load Distributed Structure in the Complex Rotational and Translational Engineering

Abstract:

In view of the large axial force column underpinning of the complex rotational transportation engineering，a new underpinning structure which with six diagonal bracings was proposed in this paper. Using SAP2000 software built four different calculating models with different support forms, and analyzed internal forces of members of the underpinning structure, discussed the load distribution effects on change of parameters including the inclined angle α between the inclined support and column, the angle θ between the inclined support horizontal projection and axis, inclined support section sizes, coupling beam section size and whether there are the horizontal forces. The results show that the load distribution effects of whole model and of single column model have little difference, but the single column model underestimates the axial forces of the inclined supports. α and θ have a great influence on load distribution effect, and smaller α is better. The load distributed result can be very good to meet the requirement of rotating shift engineering.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 542-548
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.542
• Online since: March 2013
• Authors: Er Jun Wu, Zhao Na Cao, Fen Fen Zhang, Wei Wang
• Keywords: Inclined Support, Load Distribution, Rotation Moving Engineering, Underpinning

References

[1] Zhenwu Peng, The Design and Conatruction of Underpinning Engineering [M]. Wuhan: China University of Geosciences press, 1997(in Chinese).

[2] Aiqun Li, Erjun Wu, Renhua Gao. The Technology of Building Moving Engineering [M]. Beijing: China Building Industry Press, 2006(in Chinese).

[3] Xiaojun Tang, The Research on load-sharing structure in Translating Wu Zhong Hotel [J]. Architecture Technology, 2007, 38 ( 6) : 419-421(in Chinese).

[4] Jianmin Du, Yingshu Yuan, Wei Xiang. Prediction Model of Antipunching Shear Bearing Capacity of Frame Columns Underpin System [J]. Journal of China University of Mining and Technology, 2007, 36 ( 1) : 60-64(in Chinese).

[5] Jianhong Liu. The Analysis Method of Reinforced Concrete Column Underpinning and Application [D]. Shanghai: Tongji University, 2007(in Chinese).

[6] Ying Li. The Experimental Study on the Mechanical Behavior of Column Underpinning Joint for Structure Moving [D]. Shandong: Shandong University, 2008(in Chinese).

[7] Liudong Jia, Tianle Tan, Xin Zhang, et al. Experimental Research on Mechanical Behavior of Column Underpinning Joint Bonding Interface Between Beam and Column for Structure Moving [C]. Exchange Conference of Existing Buildings Reconstruction Technology , The Nineteenth National Conference on Structural Engineering Proceedings ( Volume III ) . 2010, 340-347(in Chinese).

[8] Zhengxian Zhang, Xiaoxu Huang, Yuan Zhang . An Experimental Investigation of the New and Old Concrete Bounding Connection. [J]. Journal of South China University of Technology, 2000, 28 ( 10) : 81-86(in Chinese).

[9] CECS2950: 2011, Technical specification for underpinning for building and structures [S]. Beijing: China Planning Press, 2011(in Chinese).

[10] Tao Liu. Analysis on Underpinning under Horizontal Load in Building Moving Engineering[D]. Shandong: Shandong Jianzhu University, 2010 (in Chinese).

[11] Erjun Wu, Suling Zhang, Jianyong Wang. Combined Mechanical Analysis on Underpinning Structures and Moving Tracks for a Diagonal Building-Moving Project[J]. Journal of building structures2009, Supplementary Issure (2) : 279-284(in Chinese).

[12] Erjun Wu, Zhu Chen, Qiongjuan Zhao, et al. Internal Force Analysis of Underpinning Structure at Adverse Construction Stage in Complex Moving Engineering [J]. Construction Technology, 2011, 40 ( 337) : 35-37(in Chinese).

[13] Erjun Wu, Wei Wang, Qing Zhang, et al. Design and construction of track beams in Complex rotation transportation engineering[J]. Construction Technology. 2012. 41 ( 364) : 48-50(in Chinese).

[14] Xiaolu Gu. Ground and Foundation [M] . Beijing : China Architecture Press, 2003(in Chinese).
