3D Temperature Field Prediction and Experiment Verification of Concrete Diaphragm of Box-Girder Bridge in Early Hardening Period

Abstract:

Diaphragm is often used in box-girder bridge for controlling warping stress such those in midspan or transferring strong bearing reactions such those in ends of span. The results of a crack investigation of box-girder bridges showed that vertical cracks can be found on most diaphragms and formed in early stage of the concrete hardening. Temperature caused by hydration heat is an important factor for these cracking. Therefore temperature field prediction for the diaphragm is significant to prevent the concrete diaphragm cracking. In this paper, three-dimensional finite element analysis software ANSYS is used for simulating 3D temperature field of diaphragm of the concrete box girder bridge in all stages of construction. By calculating space temperature field of the diaphragm in different time hydration heat of the law is analyzed, combined with the measured temperature a comparative analysis to verify the validity of the temperature prediction method is conducted. The results show that simulation method is effective and accurate enough to predict the time-varying temperature field of the diaphragm.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 947-951
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.947
• Online since: March 2013
• Authors: Yi Shu Zhou, Jing Hong Liu
• Keywords: Box Girder, Bridge Engineering, Diaphragm, FEA Analysis, Temperature Field
