Design, Simulation and Optimization of a New Micro-Structural Gas Sensor

Abstract:

Micro-structural gas sensor with a new kind of electrode is designed. Platinum filament is selected as gold electrodes, and SiO₂ is used as the thermal and electricity insulation layer. The simulation results of ANSYS reveal that when the thickness of SiO₂, thickness of Si substrate, electrode with and electrode space are 50, 250, 15 and 60 µm, respectively, the sensors can own higher temperature and uniform temperature distributing in the center. The magnetic field distribution is also analyzed by ANSYS, and the results show that the new electrodes can eliminate magnetic field from the heater on the measuring signal interference, which is benefit for the improvement of sensor performance.

• Periodical: Advanced Materials Research (Volume 677)
• Pages: 125-129
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.677.125
• Online since: March 2013
• Authors: Xiao Bo Zhang, Chang Bai Liu, Li Liu, Hao Shan, Lian Yuan Wang, Shou Chun Li, Xiao Chi, Xiao Qing Bo
• Keywords: ANSYS, Magnetic Field Distribution, Micro-Hotplate, Temperature Distributing

References

[1] Noboru Yamazoe: Sensors and Actuators B: Chemical. Vol. 108 (2005), pp.2-14.

[2] Jing Wang, Peng Zhang, Jin-Qing Qi, Peng-Jun Yao: Sensors and Actuators B: Chemical. Vol. 136(2009), pp.399-404.

[3] Xian Yi, Jianjun Lai, Huafeng Liang and Xiaofeng Zhai: Journal of Physics: Conference Series. Vol. 276(2011), p.012098.

[4] Satyajit Shukla, Peng Zhang, Hyoung J. Cho, Lawrence Ludwig, Sudipta Seal: International Journal of Hydrogen Energy. Vol. 33(2008), pp.470-475.

[5] Zili Zhang, Chenbo Yin, , Chunmin Tao, Bin Zhu, Ningning Dong: Procedia Engineering. Vol. 12(2011), pp.105-110.

[6] Woo-Jin Hwang, Kyu-Sik Shin, Ji-Hyoung Roh, Dae-Sung Lee and Sung-Hoon Choa: Sensors. Vol. 11(3)(2011), pp.2580-2591.

[7] G. Wiche, , A. Berns, H. Steffes, E. Obermeier: Sensors and Actuators A: Physical. Vol. 123-124(2005), pp.12-17.

DOI: 10.1016/j.sna.2005.03.028

[8] J Puigcorbe, D Vogel, B Michel, A Vila, I Gracia, C Cane and J R Morante: Journal of Micromechanics and Microengineering. Vol. 13(2003), p.548.

[9] E Barborini, S Vinati, M Leccardi, P Repetto, G Bertolini, O Rorato, L Lorenzelli, M Decarli. V Guarnieri, C Ducatiand P Milani: Journal of Micromechanics and Microengineering. Vol. 18(2008), p.055015.

DOI: 10.1088/0960-1317/18/5/055015

[10] LIU Xin: Transducer and Microsystem Technologies. Vol. 28(2)(2009), pp.48-49.

[11] Suehle J.S. Cavicchi R.E., Gaitan M., Semancik, S.: IEEE Electron Device Letters. Vol. 14 (1993), pp.118-120.

DOI: 10.1109/55.215130

[12] Anis Nurashikin Nordin, Ioana Voiculescu and Mona Zaghloul: Microsystem Technologies. Vol. 15(2009), pp.1187-1193.

[13] ZHANG Zili, YIN Chenbo, TAO Chun, ZHU Bin: Instrument Technique and Sensor. Vol. 8 (2010), pp.1-3.

[14] Lei Xu, Tie Li, Xiuli Gao, Yuelin Wang: Sensors Journal, IEEE. Vol. 11( 2011), pp.913-919.
