UG Simulation Design of Electromagnetic Dryer

Abstract:

The electromagnetic technology of drying Paper is that we use the principle of electromagnetic heating to dry paper, which is a new paper drying technology and quite different from the traditional steam drying . This thesis is based on the principle of electromagnetic induction, combined with technical requirement of paper drying. We used the AutoCAD software design a laboratory drying device with electromagnetic, and analyzed various parts of the selection and structure, by using UG software solid modeling, assembly modeling and other modules design a three-dimensional simulation of the various parts of the electromagnetic dryer device. The simulation graphics shown that the simulation design of electromagnetic dryer is more success, which can meet the requirements of drying paper evenly.

• Periodical: Advanced Materials Research (Volume 680)
• Pages: 398-401
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.680.398
• Online since: April 2013
• Authors: Zheng Shun Wang, Zhao Hui Zhen
• Keywords: Electromagnetic Dryer, Simulation, UG

References

[1] Pan Chunrong, Luo Qingsheng. UG software in the injection mold-aided design and manufacturing [J] mechanical design and manufacturing, 2002 (6): 23-24

[2] He XiaoGao; Lu XianRong; XU Hai. Using ANSYS the the Rigid Pavements temperature stress and load stress [J]. Highways is & Automotive Applications, 2004, 6: 35-38.

[3] Wang Fengli, Song SouLian. Established in ANSYS hybrid finite element model [J] Harbin Institute of Technology, 2003, 49 (6); 22-25

[4] Shen Jian, Leeson. UG in mechanical design [J]. Mechanical Engineering and Automation, 2007 (2): 43-45.

[5] Zhang,Wei. Electromagnetic induction heating papermaking dryer and The realized of PLC control system [D]. Zhejiang University, 2006.3

[6] Wang Zhengshun. The device of electromagnetic drying dryer[P]. Chinese patent: 200420040449. 2, 2005-04-20
