Selection and Optimization of Main Process Parameters in High Pressure Waterjet Clearing HTPB Propellant

Abstract:

In order to ensure safety and efficiency in high pressure waterjet clearing HTPB propellant, the lower limit of outlet pressure was determined as 60MPa according to the compressive strength of HTPB propellant and the upper limit of outlet pressure was determined as 100MPa through ignition mode analysis and temperature rise experiment. Based on the corresponding empirical formula, the optimal target distance under different outlet pressure was calculated. Through the small size propellant clearing experiments, the main process parameters in high pressure waterjet clearing HTPB propellant were optimized. The optimal processing conditions of safe clearing are 100MPa for outlet pressure, 30mm for target distance, 0.25mm for nozzle diameter, 15minutes for single clearing time and thus the corresponding mass loss and clearing efficiency are 263.3g and 17.55g/min respectively.

You might also be interested in these eBooks

Research Efforts in Material Science and Mechanics Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 681)

Pages:

164-168

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.681.164

Citation:

Cite this paper

Online since:

April 2013

Authors:

Qi Long Han, Zuo Ming Zhu, Zhi Yong Huang

Keywords:

Clearing, High Pressure Waterjet, HTPB Propellant, Process Parameter

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] He Yuanhang, Yu Hongtao, Zhang Qingming. Ignition mode of solid propellant processed with high-pressure waterjet [J]. Transactions of Beijing Institute of Technology, 2008, 28(2): 189-191. (in Chinese).

Google Scholar

[2] Yu Hongtao, He Yuanhang, Zhang Qingming. A study on the temperature effect in solid propellant under high-pressure waterjet impact [J]. Transactions of Beijing Institute of Technology, 2008, 28(3): 189-191. (in Chinese).

Google Scholar

[3] Yu Hongtao, Zhang Qingming, He Yuanhang. Characteristics of dust explosion of AP / HTPB / ferrocene mixed system [J]. Chinese Journal of Energetic Materials, 2009, 17(3): 283-286. (in Chinese).

Google Scholar

[4] Ma Zhengxian, Gai Guosheng, Fu Chengsong, et al. Research on the mechanism of impact smash of polymer and its application [J]. Chinese Journal of Chemical Metallurgy, 1999, 20(A): 370-373. (in Chinese).

Google Scholar

[5] Li Haijun, He Yuanhang, Duan Zhuoping, et al. Research on the pressure loss in the generating process of hyperpressure waterjet [J]. Chinese Journal of High Pressure Physics, 2004, 18(2): 139-143. (in Chinese).

Google Scholar
