The Friction Welding Characteristic Analysis of the Al 7075-T6 According to the Spindle Speed and Upset Pressure

Abstract:

The propeller shaft of rear-wheel drive vehicle is an axis which transfers power from an engine to rear-wheel through differential gear box. In this study, we studied the properties of friction welding required to produce the aluminum propeller shaft of lightweight rear-wheel-drive vehicle. We studied welding property to apply Al 7075-T6 aluminum yoke to automobile connects driving shaft and differential gear box. Here, solid phase friction welding method was used. In friction welding process, the principal parameter is spindle speed, up-set pressure and up-set time. We analyzed variable characteristics of friction welding strength according to the change of the spindle rate and up-set pressure. Friction welding strength was analyzed with ultimate tensile strength test with universal testing machine (UTM). The Al 7075-T6 was used as the round bar of the diameter of 25mm. The ultimate tensile strength was 552.3 MPa. It is 94% of ultimate tensile strength of pure Al 7075-T6 material. The main parameters of characteristics are discussed in detail based on analysis of the main effects plot and multi-vari chart. Finally, the core factors to get the maximum effect of friction welding investigated.

You might also be interested in these eBooks

Materials Design, Processing and Applications

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 690-693)

Pages:

2647-2650

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.690-693.2647

Citation:

Cite this paper

Online since:

May 2013

Authors:

Il Taek Lee*, Hyun Sik Kim, Changon Park, Dong Pyo Hong, Hee Yong Kang

Keywords:

AA7075, Friction Welding, Spindle Speed, Upset Pressure

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] S. B. Kang : A study on friction welding of A2024-T6 and SM45C using insert metals (B. S. Yun and T. K. Min : Journal of KWS, Vol. 16 (1998), p.45~55)

Google Scholar

[2] S. D. Mechram : Friction welding of dissimilar pure metals (T. Mohandas and G. Madnusudhan Reddy : Journal of Materials Processing Technology, Vol. 184 (2007), p.330~337).

DOI: 10.1016/j.jmatprotec.2006.11.123

Google Scholar

[3] S. B. Kang : A study on the friction weldability of carbon steel(SM45C) to Al(A6063) ( T. K. Min ezerhi : Journal of Korean Welding Society and Machine, Vol. 16 (1995), p.57~63).

Google Scholar

[4] Bekir S. Yilbas : Investigation into the properties of friction-welded aluminum bars ( A. Z. Sahin, A. Coban and B. J. A. Aleem : Journal of Materials Processing Technology, Vol. 54 (1995), p.76~81)

DOI: 10.1016/0924-0136(95)01923-5

Google Scholar
