Research on the Normal Error of Large Aspheric Mirror Employed in Bonnet Polishing

Abstract:

The influence functions action orientation of the Bonnet Polishing (BP) process is perpendicular to the contact zone. So the normal error of the aspheric surface should be used as the residual error to calculate the dwell time. But the Z axis direction error is generally adopted as the residual error and few papers on the normal error have been reported hitherto. Its necessary to pay attention to this issue. In this paper, two algorithms which are Asphericity Subtraction (AS) algorithm and Z Axis Direction Error Transformation (ZADET) algorithm are presented to calculate the normal error of the large aspheric surface. Simulations in three different cases are organized to utilize these two algorithms, together with the comparison of them. And the comparison of the normal error and the Z axis direction error is also organized. Its found that there exists difference between AS algorithm and ZADET algorithm. Both of them can be used to calculate the normal error of the aspheric surface when the ratio value of the width to radius is small. And the difference between the normal error and Z axis direction error is considerable. So the normal error should be used as the residual error to calculate the dwell time in BP process.

• Periodical: Advanced Materials Research (Volumes 690-693)
• Pages: 3321-3324
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.690-693.3321
• Online since: May 2013
• Authors: Wei Yang, Chun Jin Wang
• Keywords: Bonnet Polishing, Large Aspheric Mirror, Normal Error, Residual Error

References

[1] R. G. Bingham, D. D. Walker, D. H. Kim, et al: Proc. SPIE 4093, 445. (2000).

[2] D. D. Walker, A. T. H. Beaucamp, V. Doubrovski, et al: Proc. SPIE 6273, 627309 (2006).

[3] D. D. Walker, A. T. H. Beaucamp, V. Doubrovski, et al: Proc. SPIE 5869, 58690E (2005).

[4] D. D. Walker, A. T. H. Beaucamp, et al: Proc. SPIE 5523, 281 (2004).

[5] W. Zhang, H. Li, G. Yu: ACTA OPTICA SINICA, 29(1):27-34(2008).

[6] F. W. PRESTON. Journal of the Society of Glass Technology, 11:277-281(1927).

[7] Jia Lide. Study on Key Techniques of Coordinate Measurement for Optical Aspherics. (Ph.D thesis, Changsha, Hunan, China, 2008).

[8] M. J. Callender, A. Efstathiou, C. W. King, et al: Proc. SPIE 6273, 62732R (2006).

[9] H. Jing, C. King, D. D. Walker: OPTIC EXPRESS 18(5), 5271-5281 (2010).

[10] H. Jing, C. King, D. D. Walker: OPTIC EXPRESS 18(3), 2036-2048 (2010).
