LED Street Lamp Module Configuration Design

Abstract:

The configuration of LED street lamp is important for its high security and low cost requirements. The modular method is introduced to design LED street lamp with independent light source and heat dissipation structure. In the single module heat pipe technology radiator is used to improve the LED street lamp of the cooling efficiency. For the 60W LED module, the optical lens are designed with the angles of 60 ° and 30 ° respectively and the average temperature is 329 K on each observation sides of the module.
