Research on Vibration Characteristic of Tamping Device Based on SIMULINK

Abstract:

The requirements of higher speed, safety and more smooth and comfortable travelling are increasing strongly, this leads to the need of predictive maintenance of railway line, tamping machines have been used for this purpose. This paper presents the results of vibration characteristic of tamping device. Firstly, the basic working principle of tamping device was simply described; Then a simulation model of tamping device was established using SIMULINK in terms of mechanism principle; Finally, some vibration parameters were researched, such as velocity, acceleration, displacement of tamping device, which reflect the vibration characteristic of tamping device. In addition, the modeling process of simulation model was described, the function of SIMULINK was also simply recommended. The main aim of this paper is to propose an analysis method on facility vibration characteristic, which visualized reflects the kinematics characteristic of mechanism. The results show that the application of the technology can make the simulation process more visualization. The modeling process more simply, thus greatly improve modeling and simulation efficiency, and directly achieve our aims.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 462-465
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.462
• Online since: May 2013
• Authors: Bin Hua, Yi Lin Chi, Xue Jun Wang, Yan Fang Ding
• Keywords: Simulation, Simulink, Tamping Device, Vibration Characteristics

References

[1] Lijun Ying, Shuwu Zhou and Lin Qi: Journal of the China Railway Society, 2004, 26 (6). (In Chinese)

[2] Changqing Kou, Hailang Zhou: Machinery on Railway Construction, 1st ed. Machine Industry Press, 2001.p.124. (In Chinese)

[3] Xuejun Wang, Yilin Chi, Wei Li, Taoyong Zhou, Xingli Geng. The research of the numerical simulation on the granular ballast bed tamping. Advanced Materials Research. Vols. 479-481, in 2012, pp.1395-1398.

DOI: 10.4028/www.scientific.net/amr.479-481.1395

[4] Xuejun Wang, Yilin Chi, Wei Li, Taoyong Zhou. Study on the DEM Simulation on the Granular Railway Ballast Bed Tamping. Advanced Materials Research. Vols. 524-527, in 2012, pp.3256-3259.

DOI: 10.4028/www.scientific.net/amr.524-527.3256

[5] Xuejun Wang, Xingli Geng. Study on the Effects of Tamping Frequency to the Compaction Degree of Trackbeds. Applied Mechanics and Materials. Vols. 178-181, in 2012, pp.1387-1391.

DOI: 10.4028/www.scientific.net/amm.178-181.1387

[6] Xuejun Wang, Yilin Chi, Fuyu Li, Qi Wang, Li Gao, Yongsheng Cao, Yongxin Peng, "Study on Discrete Element Modeling Simulation of the Railway Ballast Tamping", JDCTA: International Journal of Digital Content Technology and its Applications, Vol. 6, No. 23, p.660 ~ 668, (2012)

DOI: 10.4156/jdcta.vol6.issue23.76

[7] Xuejun Wang, Yilin Chi, Yanfang Ding, Li Gao, Ping Xu ,Yongsheng Cao, Bin Hua, "Study on the simulation of the Railway Ballast under Cyclic Loading", JDCTA: International Journal of Digital Content Technology and its Applications, Vol. 6, No. 23, p.642 ~ 650, (2012)

DOI: 10.4156/jdcta.vol6.issue23.74

[8] MinHong Weng, Zhizhen Nie: Locomotive Vehicle Technology.2008. (In Chinese)

[9] R.Perales, G.Saussine,F.Radjai: submitted to7th EUROMECH Solid Mechanics Conference. 2009, p.7.

[10] Yisong Li,Minhong Wen: Locomotive Vehicle Technology.2003.(In Chinese)

[11] Dingyu Xue, Yangquan Chen: System simulation technology and Application based on MATLAB/ Simulink[M]. Bei jing: Tsinghua University Press,2002. (In Chinese)
