Stress Analysis and Overwintering Safety Evaluation of 15×10⁴m³ Steel Crude Oil Tank in Severe Cold Area

Abstract:

In order to guarantee the overwintering safety of 15×10⁴m³ steel crude oil tank, tank structure and material properties were analyzed. A three-dimensional finite element model of the large non-anchoring oil tank was established. Based on the stress analysis, the stress distribution in different environmental temperature and drastically changed temperature was founded. The result of stress analysis indicated that the structure of the tank is safe enough to endure the conditions of winter temperature in Daqing at overwintering stage.

• Periodical: Advanced Materials Research (Volume 700)
• Pages: 144-148
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.700.144
• Online since: May 2013
• Authors: Mu Yi Liu, Xiao Yan Li, Da Wei Ji
• Keywords: Finite Element, Material Property, Safety, Steel Crude Oil Tank, Stress Analysis

References

[1] Jun Lu, Yajiao Jin. "Some question discussions about large vertical chemical metal tank's design", Liaoning chemical. Vol.10(2007), pp.6-9.

[2] Qing Yu, Yijun Wang, Yuexin Xu. "The development of large storage tank's design technology", Xinjiang Oil ＆ Gas. Vol.5(2006), pp.16-18.

[3] Qiang Liu. "The problem in the design of tank foundation and bottom plate", Oil-Gasfield Surface Engineering. Vol.26(2007), pp.6-8.

[4] Qunsheng Li. "The stress analysis of large cylindrical tank on elastic fountion", Refining Design. Vol.32(2002), pp.56-57.

[5] Houyuan Yang. "The corrosion and protection of tank's edge plate", Oil＆Gas storage and transportation. Vol.27(2008), pp.42-44.
