Design of Intelligent Actuation Time Measurement for Low Voltage Electrical Apparatus

Abstract:

In order to measure the actuation time of low voltage electrical apparatus, this paper designs an intelligent timing device triggered by single and double circuits. The device adopts the system structure of the upper and lower computer so that the action signals will be collected and measured by lower computer through conditioning, and the measurement results will be shown on the digital tube. Through communication with lower computer by RS232 serial port, the upper computer can display the real-time status and results of the measurement and issue commands to control the operation of the device. Utilizing modular programming, and targeted for the action characteristics of different components, this paper puts forward adaptive optimization testing algorithm, which can achieve single / double circuit timing, digital display, upper computer monitoring, manual / programmed control, the positive and negative transition trigger of the adaptive input signal and other functions. After the tests on actual functionality and reliability, the device is successfully applied in aircraft power supply system. The results suggest that the function of the timing device is complete, its structure is simple, easy to maintain, and it can meet the measurement requirements of the actuation time for low voltage electrical components.

• Periodical: Advanced Materials Research (Volume 709)
• Pages: 379-382
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.709.379
• Online since: June 2013
• Authors: Zhen Wang, Jian Fei Si, Li Sheng Hui
• Keywords: Adaptive Optimization Algorithm, Dual-Pulse Triggering, Low Voltage Electrical Components, Lower Computer System, STM32, Timing of Actuation Time, Upper Computer System

References

[1] Jiangguo Lu, Hui Guo. Development of Measurement and Test Technology for Low Voltage Electrical Apparatus [J]. Low Voltage Apparatus, 2002(1):48-52. (In Chinese)

[2] Uchimura K, Aida T. Measurement of Electromagnetic Interference from DC- Switching Relays [C]. Conference on Precision Electromagnetic Measurements, 1988:319-320

DOI: 10.1109/cpem.1988.671321

[3] Frost B J.A New Generation of Relay Test Equipment Addresses Old Relay Measurement Problem [C] .Proceedings of 45th Relay Conference,1998.

[4] Majumder Sumit, McGruer N E, Zavracky PauI M, et al. Contact Resistance Modeling and Measurements of an Electrostatically Actuated Micromechanical Switch[C]. The 1998 ASME International Mechanical Engineering Congress and Exposition.

DOI: 10.1115/imece1998-1265

[5] Yiqing Liu. Performance testing of complete digital relays based on ATP-EMTP and IEC61850-9-2[C]. 2011 4th International Conference on Electric Utility Deregulation and Restructuring and Power Technologies (DRPT), 83-87

DOI: 10.1109/drpt.2011.5993867

[6] Sun Y, Liu C.-C, Christie R.D.,et al. RETEX (Relay Testing Expert): An Expert System for Analysis of Relay Testing Data [C]. Proceedings of the 1991 IEEE Power Engineering Society:376-384

DOI: 10.1109/tdc.1991.169534

[7] Chunyi Shi. Study on the measurements of electromagnetic relays' time parameter. Electromechanical Components, 2009, (3) :38-47(In Chinese)
