Solidworks Engineering Drawing Automatically Adjust Technology and Implementation

Abstract:

Aiming at the problem of the engineering drawing after generating from parametric design including unreasonable layout, disharmonious proportions and nonstandard labeling, with VB6.0 software for the tool, combined with the Access database, the paper proposes the method of engineering drawing automatic adjustment. It realizes automatic adding of the project chart attribute, automatic adjustment of view scale, view position, annotation position and generating of material list automatically. Through this technology, it can develop automatic system of adjusting engineering drawing, which greatly improves the efficiency of parametric design and applying to actual production.
