Dynamic Characteristics Analysis of Axle Box Spring by FEM

Abstract:

Axle box spring of railway vehicle is the structure of helical spring in series with rubber pad to reduce working stress of helical spring and absorb high-frequency vibration. Rubber pad model was built. Static and dynamic characteristics were researched in axial and radial directions. The results show that the static stiffness of rubber pad decreases with the increase of radial displacement and increases distinctly with the increase of the amount of compression; The dynamic stiffness of rubber pad increases with the decrease of the excitation force in the case of the same excitation frequency and decreases with the decrease of the frequency in the case of the same excitation displacement. Axle box spring method was established and the amplitude-frequency curve of dynamic stiffness of the spring was presented. The results provide a theoretical basis to research the dynamic performance of railway vehicle.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 1535-1540
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.1535
• Online since: June 2013
• Authors: Li Liu, Wei Hua Zhang, Dong Li Song
• Keywords: Axle Box Spring, Dynamic Characteristic, Finite Element Method (FEM), Helical Spring, Rubber Pad

References

[1] Caiying Mi, et al. Stability Analysis of the Secondary Suspension System of Tilting Diesel Locomotive-Stiffness Method, Journal Of Southwest Jiaotong University, Vol.35　No.6 Dec. (2000)

[2] Caiying Mi, et al. Horizontal directional rigidity and stability analysis of system of paralleled helical spring in series with rubber spring at their one end, Diesel Locomotives, No.10 (total332), (2001)

[3] Caiying Mi. A new method to determine the lateral rigidity of a system formed by the high and round spring in series with rubber springs at its two ends, Diesel Locomotives, No.4(total314), (2000)

[4] Caiying Mi. A Method for Analyzing the Lateral Stiffness of Flexcoil Springs, Journal Of Southwest Jiaotong University, Vol.33, No.3, (1998)

[5] Hongwen Yan. Application of FEM to Design of Rubber Elements in Rolling Stock, Electric Drive For Locomotives, No.6, Nov.10,(2007)

[6] Li Liu, Weihua Zhang. Frequency variety analysis and equivalent algorithm of metal spring stiffness, Journal Of Traffic And Transportation Engineering, vol.7,No.5,2007:24-27

[7] Li Liu, Weihua Zhang, Study on dynamic characteristics of metal helical spring, Sciencepaper Online , vol.2,No.9,2007:678-684

[8] Zheng Meng. "Research On Rubber Spring Dynamic Stiffness And Its Influence On Subway Vehicle Dynamics"[D], Southwest Jiaotong University Master Thesis, (2011)

[9] Qingqun Lan and Pingbo Wu. Static and dynamic analysis of rubber spring for rolling stock, Machinery Design＆Manufacture, 2008,11

[10] Weixiao WANG, et al. Structure Analysis of Cone Rubber Spring, Railway Rolling Stock, vol.47,No.2,(2009)

[11] Jiwei Zhang. Finite Element Analysis of Dynamic Characteristics for Main Rubber Spring of Hydraulic Engine Mount，Jilin University Master Thesis，(2007)

[12] Jie Wu. et al. Computational Method for Dynamic Properties of Rubber Isolators Using Hyperelastic-viscoelastic-plastoelastic Constitutive Model, Journal Of Mechanical Engineering, vol.46,No.14, (2010)

DOI: 10.3901/jme.2010.14.109

[13] Liang Zuo. Finite element analysis of Common Rubber Components Used in Locomotive and Vehicle, Southwest Jiaotong University Master Thesis,(2006)

[14] Luhong Ma, et al. Analysis Of Combined Elastic Damping Devices on Multiple Dof Parallel Mechanism, Journal Of Mechanical Engineering, Vol.40,No.1, (2004)

DOI: 10.3901/jme.2004.01.021
